SCAN TOOL CONNECTING

All functions which could previously be performed with V.A.G 1551/1552 can also be performed with the new
tester VAS 5051 in the operating mode vehicle OBD.

Connecting VAS 5051

z

With ignition switched off, connect tester VAS 5051 to Data Link Connector using diagnosis cable VAS
5051/1 or VAS 5051/3.

Selecting operating mode:

z

Press button on display for "Vehicle OBD".

Selecting vehicle system:

z

Press "03 - Brake electronics" on display.

WARNING:

z

You must always secure testing and measuring equipment on the
rear seat.

z

When vehicle is being driven, only a second technician operate this
equipment.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 155: Connecting Tester VAS 5051 To Data Link Connector Using Diagnosis Cable VAS 5051/1
or VAS 5051/3
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The control module identification and coding are indicated on the display.

Selecting diagnosis function:

All diagnostic functions available are indicated on the display.

z

Press button on display for desired function.

z

Further measures see repair procedures.

V.A.G 1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTION

Special tools and equipment

NOTE:

The following test sequences are for V.A.G 1551 scan tool.

NOTE:

z

All functions that have so far been carried out with V.A.G 1551 can now
also be carried out with the tester VAS 5051.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



z

V.A.G 1551 scan tool

Fig. 156: Identifying V.A.G 1551 Scan Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1551/3 or 1551/3A adapter cable



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 157: Identifying V.A.G 1551/3 Or 1551/3A Adapter Cable
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Work sequence

z

Connect V.A.G 1551 scan tool using cable V.A.G 1551/3.

z

Connect VAS 5051, see ON BOARD DIAGNOSTIC (OBD), PERFORMING .

Fig. 158: Connecting V.A.G 1551 Scan Tool Using Cable V.A.G 1551/3
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Indicated on display: See Fig. 159 .

1)

 Is displayed alternately



NOTE:

z

If the display does not indicate as described in the work sequence:

See Scan tool operating instructions

z

If due to an input malfunction "Malfunction in the data transfer!" is
displayed, disconnect wire off scan tool, reconnect and repeat work
step.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle
