Glass, Window Regulators - New Beetle

DOOR WINDOWS

TOOLS

Special tools, workshop equipment, testers, measuring instruments and auxiliary items required

z

T 10011 Socket Insert.

FRONT DOOR WINDOW, ASSEMBLY OVERVIEW

1. Window guide

z

Pushed onto flange.

2. Door window

z

Removing, see FRONT DOOR WINDOW, REMOVING .

z

Adjusting, see DOOR WINDOW, ADJUSTING .

3. Door

4. Outer window guide

z

Pushed onto flange.

5. Window slot seal

z

Pushed onto flange.

6. Trim

7. Phillips screw

8. Spring nut

9. Bolt/screw

z

20 N.m.

10. Window slot seal

z

Pushed onto flange.

11. Assembly carrier

z

Removing and installing, see ASSEMBLY CARRIER, REMOVING AND INSTALLING .

z

Window regulator is part of assembly carrier.

12. Crank handle for manually operated window

z

Bolted unto assembly carrier from back of carrier.

13. Window electric motor

z

Bolted unto assembly carrier from front of carrier.

NOTE:

The following list refers to items in Fig. 1 .



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



14. Bolt/screw

z

8 N.m.

15. Cover cap

16. Bolt/screw

z

10 N.m.

Fig. 1: Exploded View Of Front Door Window Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

FRONT DOOR WINDOW, REMOVING

z

Remove front door trim.

See DOOR TRIM .

z

Pry out cover caps -1-.

Fig. 2: Prying Out Cover Caps



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lower door window until clamp securing bolts/screws are accessible.

z

Loosen bolts/screws -2- and press clamps apart.

z

Lower window regulator further.

z

Lift rear of door window and swing out of door forward in direction of -arrow-.

Fig. 3: Lifting Rear Of Door Window And Swinging Out Of Door
Courtesy of VOLKSWAGEN OF AMERICA, INC.

DOOR WINDOW, ADJUSTING

z

The door window clamps must be positioned in the assembly openings.

z

Push door window -1-- into window guide -arrow- and tighten clamps with bolts/screws -2-(10 N.m).

z

Then perform functional check.

NOTE:

If the work sequence cannot be carried out because there is a malfunction
with the electric window motor, remove motor to slide window down.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



Fig. 4: Adjusting Door Window
Courtesy of VOLKSWAGEN OF AMERICA, INC.

WINDOW REGULATOR, TROUBLESHOOTING

Prior to changing a window regulator, due to a binding condition, please follow these steps.

If door window binds in up (raised) position, activate pinch protection using following:

z

Bring window glass all way up and press window up switch 2X (two times).

z

Bring window glass all way down and press window down switch 2x (two times).

z

Cycle window glass up and down. You must hear a "clunk" noise, which means that glass is now fully
seated on window regulator.

z

Cycle window up and down several times to verify effectiveness of the repair.

ASSEMBLY CARRIER, REMOVING AND INSTALLING

Window regulators, door lock and loudspeaker are secured to assembly carrier.

Door lock can only be removed in conjunction with assembly carrier.

Assembly carrier can only be removed when door window clamps of window regulator are unscrewed. To do

NOTE:

z

Glass must be tight on the clamp carrier of the window regulator.

z

The window channel opening must be uniform and consistent all the way
around the opening and at the weld joint at the lower A-pillar area.

z

If the glass is not going all the way down and/or a "clunk" noise occurs,
check the motor programming using the VAS 5051 and check the system
for any malfunctions or Diagnostic Trouble Codes (DTC).

z

These steps must be performed when replacing the old motor with a new
one or when the battery is discharged.
