Fig. 21: Pulling Rear Edge Of Trim (With Clock) Downward Off Roof Trim
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press interior mirror -1- downward at an angle -arrow- off the retaining plate (spring clip in mirror base).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



Fig. 22: Pressing Interior Mirror Downward At An Angle Off Retaining Plate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pry vanity light out using a screwdriver and disconnect connections.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



Fig. 23: Prying Vanity Light Out
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unhook sun visor -1- from mounting -2-.

z

Pry out cover caps -6-.

z

Remove bolt/screw -5-.

z

Release sun visor mounting -4- from mounting and separate connection -3-.

z

Pry off cover caps -7-.

z

Remove screws -8- and remove mounting -2-.

z

Remove hand holds on left and right-hand sides of roof.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



Fig. 24: Removing Sun Visor From Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Open hand hold -1- downward.

z

Pry cover -2- upward using a screwdriver and fold open.

z

Remove Phillips screws -3- and remove handle -1-.
