Slide sun blind to rear.

z

Tilt (raise) sliding/tilting sunroof open

z

Unclip lower trim -2- in forward area (working from outer side inward to center of vehicle) and unhook at
rear.

z

Unclip upper trim -1- at front, the center and unhook at rear.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



Fig. 4: Removing Lower Trim Clip In Forward Area
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove securing screws (Torx(R) insert T25; 4.5 N.m).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



Fig. 5: Removing Sliding/Tilting Roof Panel Upward
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove sliding/tilting roof panel upward.

SLIDING/TILTING SUNROOF GLASS PANEL, INSTALLING

Panel must be installed in "0" position (panel closed).

"0" position:

The mark -arrow- on the rear of the guide upper part -1- must lie within the marks -dimension a- on the guide

NOTE:

The sliding/tilting sunroof must not be moved to position "Open" when glass
panel is removed, this is because water channel will not be compressed by
glass panel and can therefore may tilt in roof.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



rail gate -2-, on both sides.

Fig. 6: Marking Dimension On Guide Rail Gate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The guide channel -2- must be located in the guide rails (cannot be moved by hand).

If this is not the case, adjust parallel running, see PARALLEL RUNNING, ADJUSTING .

z

Place sliding/tilting sunroof panel in position from above and screw in securing screws (guide rail/panel).
