Fig. 98: Exploded View Of Convertible Top Front Latch Assembly (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

CONVERTIBLE TOP FRONT CATCH, ASSEMBLY OVERVIEW

1. Roof cross member

2. Bolt/screw

3. Micro switch

4. Plate

5. Convertible top catch

6. Bolt/screw

z

10 N.m.

Fig. 99: Exploded View Of Convertible Top Front Latch Assembly (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The following list refers to items in Fig. 99 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



CONVERTIBLE TOP FRONT CATCH, REMOVING AND INSTALLING

Removing

z

Remove roof member cross member trim.

See ROOF CROSS MEMBER INNER AND OUTER TRIM (CONVETIBLE) REMOVING AND
INSTALLING .

z

Disconnect micro switch connection from right side.

z

Remove bolt/screw -6-.

Fig. 100: Exploded View Of Convertible Top Front Catch Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Installation is reverse of removal.

NOTE:

z

The convertible top can be adjusted within the elongated holes for the
convertible top catch -5-.

z

The convertible top must lie centrally on the roof cross member and lie
evenly at the A-pillars.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



CONVERTIBLE TOP REAR CATCH, ASSEMBLY OVERVIEW

1. Convertible top catch

z

Removing:

„

Remove side trim panel.

See SIDE PANEL TRIM, REMOVING AND INSTALLING

„

Open convertible top or work from the inside of the vehicle with top closed.

„

Disconnect electrical connection -6-.

„

Remove bolts/screws -3-.

z

Installing:

„

Install bolt/screw -3- and tighten lightly.

„

Connect electrical connection -6-.

„

Align module for convertible top catch.

„

Close convertible top if decided to open it previously.

„

When convertible top has engaged tighten bolts/screw -3-.

„

Then perform functional check.

2. Washer

z

Qty. 7.

3. Bolt/screw

z

10 N.m.

z

Qty. 7.

Fig. 101: Exploded View Of Convertible Top Front Catch Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The following list refers to items in Fig. 102 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



4. Cable for emergency release

5. Servo motor

6. Electrical connection

7. Micro switch (convertible top closed)

8. Micro switch (convertible top open)

Fig. 102: Removing Convertible Top Rear Catch Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ELECTRO/HYDRAULIC CONVERTIBLE TOP, COMPONENTS

1. Right hydraulic cylinder

z

Removing, see HYDRAULIC CYLINDER, ASSEMBLY OVERVIEW .

2. Convertible Top Open Position Switch -F171-

z

Installed only on right-hand side.

z

Unclip from hydraulic cylinder -1-.

3. Hydraulic hoses

z

Removing and installing, see HYDRAULIC HOSES .

4. Convertible Top Control Module -J256-

z

On right in luggage compartment.

z

Further information, see appropriate WIRING DIAGRAM article

5. Left hydraulic cylinder

z

Removing, see HYDRAULIC CYLINDER, ASSEMBLY OVERVIEW .

6. Plug

7. Oil filler plug

z

5 N.m.

NOTE:

The following list refers to items in Fig. 103 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
