Volkswagen New Beetle. Manual - part 539

z

Press beading into roof leading edge.

z

Align marks on the padding material with the marks on the convertible top frame.

z

Slide clamping profile, tensioning belt, padding material into bracing hoops 2 and 4.

z

Install securing bolts/screws into beading along sides of bracing hoops 2 and 4.

z

Secure elastic strap to convertible top frame with a bolt/screw.

z

Install securing bolt/screw for guiding rubber cable and padding material loop to bracing hoop 3 for
convertible top frame tensioning cable.

z

Guide wiring for heated rear window and hinge through padding material.

z

Pull rubber cable through loop on convertible top lining.

z

Press padding material clamping beading into convertible top fabric retaining frame and secure with
bolts/screws.

CONVERTIBLE TOP LINING, REMOVING AND INSTALLING

z

Remove side trim panel.

See SIDE PANEL TRIM, REMOVING AND INSTALLING .

z

Remove head restraint cover

See BACKREST (CONVERTIBLE), REMOVING AND INSTALLING .

z

Open convertible top to half open position.

z

Observe security rules, see CONVERTIBLE TOP .

z

Remove roof leading edge trim, see CONVERTIBLE TOP FRONT LATCH, ASSEMBLY
OVERVIEW .

z

Remove bolts/screws -arrows- from roof leading edge.

NOTE:

z

On models with an electro/hydraulic convertible top the motors for the rod
flaps must remain connected to the wiring harness so that the convertible
top may be moved hydraulically.

z

Position side trim panels in the vehicle so that the rod flaps can move
freely.

z

The servo motors may be disconnected from the flap motor.

z

Protect the vehicle against possible paintwork damage with suitable
protective covers and textile reinforced adhesive tape.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 58: Removing Bolts/Screws From Roof Leading Edge
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull clamping beading -1- out of bracing hoop.

Fig. 59: Pulling Clamping Beading Out Of Bracing Hoop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull clamping profile -1- off bracing hoop 2.

WARNING:

For security reasons, hold tension on elastic strap while removing
screw



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 60: Pulling Clamping Profile From Bracing Hoop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull insert profile -1- off dart out of bracing hoop clamping profile.

Fig. 61: Pulling Insert Profile Off Dart Out Of Bracing Hoop Clamping Profile
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull darts between bracing hoop 3 and retaining frame.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 62: Pulling Darts Between Bracing Hoop And Retaining Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull clamping profile -1- off bracing hoop 4.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
