Volkswagen New Beetle. Manual - part 523

z

Remove screw -12-.

z

Take off trim -11-.

z

Unclip left cover cap - 3 - and right cover cap - 6 -.

z

Unclip wiring under seat.

z

Disconnect connections -1- for seat backrest heater, if part of original equipment.

Fig. 8: Disconnecting Connections For Seat Backrest Heater And Airbag
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pry out retaining clip -2- and take out guide -3- for airbag wiring.

z

Remove bolt -4- on both sides of seat and take backrest off. See Fig. 8 .

Installing

Install in reverse order of removal.

HEAD RESTRAINT GUIDES, REMOVING AND INSTALLING

Removing

z

Remove head restraint form backrest.

z

Press backrest padding below guide -2- downward and release the locking lug -1- with a screwdriver or
drift.

NOTE:

The bolts -4- must be secures with locking fluid D 000 600 A2 (torque setting 20
N.m).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



Fig. 9: Head Restraint Guides
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull head restraint guides -2- out.

Installing

Install in reverse order of removal.

SEAT HEIGHT ADJUSTMENT, ASSEMBLY OVERVIEW

1. Seat trim

z

Front right

2. Bolt/screw

3. Cover cap, right

4. Seat

5. Backrest

6. Transfer rod

z

For backrest adjustment

7. Adjustment knob

z

For lumbar support

8. Cover cap, left

9. Spacer ring

10. Adjustment knob

z

For backrest

11. Cover cap

z

Qty. 2

NOTE:

The following list refers to items in Fig. 10 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



12. Bolt/screw

z

Qty. 2

13. Adjustment lever

z

For seat height

14. Seat trim

z

Front left

15. Seat height adjustment element

16. Spring

z

Qty. 2

17. Bolt/screw

Fig. 10: Identifying Seat Height Adjustment Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

SEAT HEIGHT ADJUSTMENT, REMOVING AND INSTALLING

Removing

z

Remove seat. See FRONT SEATS, REMOVING AND INSTALLING .

z

Remove bolt - 2 - and unclip trim -1-.

z

Unclip cover caps -11- (Qty. 2) and remove bolts -12- (Qty. 2) and remove adjustment lever - 13-.

z

Remove bolt - 17 - and unclip trim -14-.

NOTE:

z

The removal and installation procedures may have to be modified slightly
depending on equipment variants.

z

Raise seat to its highest position before removing seat, this action relieves
as much tension as possible on the spring -16-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



Fig. 11: Locating Seat Height Adjustment Mechanism
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unhook spring -2- carefully. See Fig. 12 .

z

Remove bolts -arrows- and pull seat height adjustment element -1- out of seat frame.

Fig. 12: Removing Seat Height Adjustment Element From Seat Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

FIRE EXTINGUISHER BRACKET (FRONT PASSENGER'S SIDE), ASSEMBLY OVERVIEW

NOTE:

The torque setting for the bolts -arrow- is 10 N.m.

NOTE:

The following list refers to items in Fig. 13 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle
