z

Qty. 2

Fig. 13: Exploded View Of Center Console - From 02.01 To 04.03
Courtesy of VOLKSWAGEN OF AMERICA, INC.

CENTER CONSOLE FROM 02.01 TO 04.03, REMOVING AND INSTALLING

Removing

z

Remove center armrest. See FRONT ARMREST, REMOVING AND INSTALLING .

z

Remove ashtray -11-. See REAR ASHTRAY FROM CENTER CONSOLE FROM 02.01 TO 04.03,
REMOVING AND INSTALLING . Remove drink holder - 5 -. See DRINK HOLDER FROM 02.01,
REMOVING AND INSTALLING .

WARNING:

Before working on electrical system: Disconnect battery Ground (GND)
strap. See BATTERY, DISCONNECTING AND RECONNECTING .

NOTE:

z

The removal and installation procedures may have to be modified slightly
depending on equipment variants.

z

Obtain radio unit code before disconnecting battery.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 14: Exploded View Of Center Console - From 02.01 To 04.03
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull parking brake lever on, release trim using a screwdriver and pull forward off parking brake lever -
arrow-.

Fig. 15: Removing Trim And Pulling Parking Brake Lever - From 02.01 To 04.03
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unclip gearshift boot -1- from center console and slide upward.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 16: Removing Gearshift Boot From Center Console - From 02.01 To 04.03
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Only if required for further work, remove clamp -2- and remove gearshift along with boot.

See SELECTOR MECHANISM ON TRANSMISSION SIDE, AS OF 06.99 .

z

Pull cover - 8 - off and separate cigarette lighter - 7 - connection.

z

Pull cover - 9 - off and separate power socket - 10 - connection.

z

Remove insert - 12 -.

z

Unclip cover caps - 3 -and remove screws - 2 -.

z

Remove screws - 4 - and - 13-.

z

Lift rear of center console -1-, pull to rear and remove upward over the gearshift.

Fig. 17: Exploded View Of Center Console - From 02.01 To 04.03
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Installing clamp:



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Installing

Install in reverse order of removal.

Fig. 18: Exploded View Of Center Console - From 02.01 To 04.03
Courtesy of VOLKSWAGEN OF AMERICA, INC.

REAR ASHTRAY FROM CENTER CONSOLE FROM 02.01 TO 04.03, REMOVING AND
INSTALLING

Removing

z

To remove ashtray -1-, turn item to the left and take off upward.

NOTE:

After reconnecting battery, ensure the vehicle equipment (radio, clock, electric
windows) is checked as per Workshop manual and/or Owner's manual.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle
