Fig. 151: Pressing Needle Roller Bearing Into Reverse Shaft Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

FINAL DRIVE, DIFFERENTIAL

FLANGE SHAFT OIL SEALS (TRANSMISSION INSTALLED), REPLACING

Left flange shaft oil seal, removing

Special tools and equipment



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 152: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VW 771 Multipurpose tool

z

VW 771/37 Puller hooks

z

3106 Drift

z

V.A.G 1331 Torque wrench

z

V.A.G 1332 Torque wrench

Removing

z

Remove center and left noise insulation tray under engine/transmission if installed.

z

Remove drive shaft

See FRONT AXLE SHAFT



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



z

Remove flange shaft securing bolts by screwing two bolts into flange and counterhold flange shaft using
a lever.

z

Place container under transmission.

z

Remove flange shaft with spring.

z

Pull out seal for flange shaft with VW 771 and VW 771/37.

Fig. 153: Removing Left Oil Seal For Flange Shaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Drive new seal into sleeve onto stop, when doing this do not cant seal.

NOTE:

z

Do not damage sleeve, otherwise leaks will occur.

z

Replace sleeve if damaged. See Pulling sleeve in .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 154: Installing Left Oil Seal Into Sleeve Onto Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Fill space between sealing lip and dust lip with sealing grease G052 128 A1.
