Fig. 111: Pressing In Small Tapered Roller Bearing Outer Race
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pulling off small tapered roller bearing inner race



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 112: Pulling Off Small Tapered Roller Bearing Inner Race
Courtesy of VOLKSWAGEN OF AMERICA, INC.

A. Vice clamps/vice

{

Install gripping device and tension behind bearing rollers, then turn bearing and retension gripping



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



device.

Pressing on small tapered roller bearing inner race

Fig. 113: Pressing On Small Tapered Roller Bearing Inner Race
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pressing off 3rd and 4th gear synchro-hub/locking collar, 2nd, 3rd and 4th gear wheels with transmission housing needle
roller bearing sleeve



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 114: Pressing off 3rd and 4th gear synchro-hub/locking collar, 2nd, 3rd and 4th gear wheels with
transmission housing needle roller bearing sleeve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

A. Separating device 22 ... 115 mm, e.g. Kukko 17/2

B. Hex bolt 17 mm AF - M10 x 20

Pulling off locking collar with synchro-hub and bearing support

NOTE:

Support separating appliance so that the 1st and 2nd gear locking collar is
not pulled off at the same time.
