Fig. 60: Driving In Sleeve And Oil Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Clean the sitting place of oil seal in transmission.

A. Screw threaded rod from assembly tool 3066 into differential threaded piece

B. Nut M12

z

Drive sleeve over press piece T10148 onto stop by turning on nut -B-.

SELECTOR MECHANISM ON TRANSMISSION SIDE, UP TO 05.99, DISASSEMBLING AND
ASSEMBLING

NOTE:

When transmission is disassembled press sleeve in with press piece
T10148 onto stop.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Special tools and equipment

z

VW 439 Guide pin

z

VW 402 Press plate

z

VW 408 A Press tool

z

VW 447 H Press plate

z

3129 Fitting tool

Fig. 61: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Selector shaft

2. Stop ring

NOTE:

The following list refers to items in Fig. 62 .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



3. Ball sleeve

z

Removing. See Removing ball sleeve from selector mechanism cover

z

Pressing in. See Driving ball sleeve into selector mechanism cover

4. Oil seal

z

Pry out with screwdriver

z

Installing. See Installing oil seal onto stop

5. Selector mechanism cover

6. Sleeve

z

The lug points to reverse light switch

z

Lightly coat lug with MoS

2

 grease

7. Hex nut, 25 N.m

z

Self-locking

z

Always replace

8. Housing

z

For back-up light switch

9. Bolt

10. Cap

z

For transmission breather

11. Sleeve

z

Drive in onto stop if present as an individual part

12. Gear selector lever

z

Install so that master spline aligns with selector shaft

z

Can be replaced with selector mechanism installed

z

Installation position. See GEAR LEVER

13. Relay lever

z

Installation position. See GEAR LEVER

14. Nut, 15 N.m

15. Actuating arm

z

With axis pin for mounting relay lever

z

Installation position. See SELECTOR MECHANISM

16. Bolt

z

Press into actuating arm

17. O-ring

z

Pull onto actuating arm axis pin

18. Spacer

z

Press into relay lever

19. Locking bolt, 40 N.m



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



20. End cover

Fig. 62: Exploded View Of Selector Shaft Assembly (Up To 05.99)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing ball sleeve from selector mechanism cover
