Unscrew bolt for selector mechanism for reverse gear -B-.

Fig. 28: Removing Selector Forks With Selector Plates
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



z

Remove nuts for output shaft bearing support. See ASSEMBLING , item -B-

z

Remove reverse gear -A-, input shaft -B- and output shaft -C- one after other from clutch housing.

Fig. 29: Removing Reverse Gear, Input Shaft And Output Shaft From Clutch Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Take out differential.

Assembling

z

Install differential.

z

Always replace sealing rings (arrows) for output shaft bearing support.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 30: Installing Sealing Rings To Output Shaft Bearing Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install input shaft, output shaft and reverse shaft together.

z

Tighten nuts for output shaft bearing support.

z

Clean locking fluid remnants from threads in reverse shaft support. See INSTALLATION POSITION
5TH GEAR WHEEL . Remnants can be removed using a tap.

z

Install reverse shaft support.

z

Install selector mechanism/reverse gear.

Installation position reverse gear

NOTE:

The illustration only shows 3 of the 4 sealing rings.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 31: Installation Position Reverse Gear
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install selector forks together with selector plates.

z

Screw M 8 x 100 mm studs -A- into reverse shaft support so that shaft is aligned after installing
transmission housing.
