to 25 N.m an additional 1/4 turn 90°.

REVERSE SHAFT, DISASSEMBLING AND ASSEMBLING

Special tools and equipment

z

VW 454 Press piece

z

VW 447 H Press plate

z

VW 411 Press tool

z

12-551 Centering mandrel

z

VW 401 Press plate

z

VW 408 A Press tool

Fig. 146: Identifying Special Tools And Equipment



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Clutch housing

2. Needle roller bearing

z

Pulling out. See Pulling needle roller bearing out of clutch housing

z

Pressing in. See Pressing needle roller bearing into clutch housing

3. Reverse gear wheel

4. Circlip

z

Always replace

5. Reverse sliding gear wheel

z

Before replacing remove circlip

z

Shoulder faces to reverse gear wheel

6. Reverse shaft

z

Removing. See Assembly sequence

7. Needle roller bearing

z

Pressing out. See Pressing needle roller bearing out of reverse shaft support

z

Pressing in. See Pressing needle roller bearing into reverse shaft support

8. Reverse shaft support

z

Removing and installing. See Assembly sequence

NOTE:

After disassembling, always replace needle roller bearing in clutch housing and
reverse shaft support.

NOTE:

The following list refers to items in Fig. 147 .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 147: Dissembled View Of Clutch Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pulling needle roller bearing out of clutch housing



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 148: Pulling Needle Roller Bearing Out Of Clutch Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

A. Counter support, e.g. Kukko 22/1

B. Internal extractor 14.5 ... 18.5 mm, e.g. Kukko 21/2

Pressing needle roller bearing into clutch housing

NOTE:

The needle bearing is destroyed during removal and must be replaced.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
