Volkswagen New Beetle. Manual - part 2443

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install pivot pin (arrow) for selector forks. To do this align selector mechanism with a screwdriver so that
relevant pivot pin can be installed.

Fig. 34: Installing Pivot Pin
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install selector shaft cover



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Install selector shaft as follows:

z

Place selector plates in neutral.

z

Locate lug (arrow -1-) in recess in transmission housing. Position selector shaft so that selector finger
(arrow -2-) is inserted in selector plates.

Fig. 35: Installing Selector Shaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install selector shaft cover.

Installation position 5th gear wheel

The circumferential groove (arrow) faces to transmission housing.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 36: Identifying Installation Position 5th Gear Wheel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Drive on 5th gear wheel.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 37: Installing Drive On 5th Gear Wheel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking 5th gear synchro-ring

z

Before installing 5th gear wheel and synchro-ring press synchro-ring onto cone of gear wheel and
measure gap -a- with a feeler gauge.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
