Volkswagen New Beetle. Manual - part 2434

Fig. 4: Identifying Transmission Layout (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Gear ratios

I - 1st gear

NOTE:

The following list refers to items in Fig. 5 .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



II - 2nd gear

III - 3rd gear

IV - 4th gear

V - 5th gear

R - Reverse gear

A - Final drive

T - Speedometer drive

Arrows point in direction of travel

Fig. 5: Identifying Transmission Layout (2 Of 2)



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

CALCULATING OVERALL RATIO "I"

Example:

CALCULATING OVERALL RATIO "i" (EXAMPLE)

i= Z

2

 "DIVIDE" Z

1

1

 )



I

G

 =Gear ratio = ZG

2

 / ZG

1

 =36 / 43 = 0.837



I

A

 = Final drive ratio = ZA

2

 / ZA

1

 = 72 / 17 = 4.235



i = Total ratio

= I

G

 x I

A

 = 0.837 x 4.235 = 3.545



1)

 Z

1

 = No. of teeth driving gear, Z

2

 = No. of teeth driven gear



GENERAL REPAIR INSTRUCTIONS

To ensure perfect transmission repairs, the greatest care and cleanliness as well as the use of good and proper
tools is essential. Obviously, the basis rules for safety are also applicable during repair work.

A number of generally valid instructions applicable for the various repair procedures - which were previously
repeated a number of times at numerous places in the Repair Manual - are summarized here. They apply to this
Repair Manual.

Transmission

z

When installing make sure that the dowel sleeves between the engine and transmission are correctly
located.

z

When changing a transmission fill with gear oil to the lower edge of the filler hole.

z

Capacities and specifications. See CODE LETTERS, TRANSMISSION APPLICATION, RATIOS,
CAPACITIES .

Gear

5th gear

Final drive

Driving gear

ZG

1

 = 43

ZA

1

 = 17

Driven gear

ZG

2

 = 36

ZA

2

 = 72

NOTE:

z

If the oil level is topped off with the transmission installed, carry out oil
level check as follows:



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Gaskets, sealing rings

z

Thoroughly clean joint surfaces and apply sealant AMV 188 200 03.

z

Apply sealant uniformly but not too thick.

z

Replace "O-rings".

z

Radial shaft oil seals.

Before installation:

z

Lightly oil outer edge, fill space between sealing lips -arrow-with grease G 052 128 A1.

z

Fill with oil to the lower edge of the filler hole and install filler plug. Start
the engine, engage a gear and allow transmission to turn for approx. 2
minutes. Switch off engine and again top off oil to lower edge of filler hole.
