Volkswagen New Beetle. Manual - part 215

Removing

z

Remove door trim.

See DOOR TRIM .

z

Disconnect electrical connection.

z

Release switch housing -A- by pressing sideways out from locking device in mounting frame -B- and
remove.

Fig. 5: Removing Switch Housing For Interior Lock, Passenger Side
Courtesy of VOLKSWAGEN OF AMERICA, INC.

CAUTION:

z

Switch off all electrical consumers.

z

Switch ignition off and remove ignition key.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Lights, Switches - Interior, Anti-Theft - New Beetle



Installing

z

Connect electrical connection.

z

Insert switch -A- in recess in mounting frame -B-and engage.

z

Install door trim.

SWITCH FOR REMOTE/FUEL TANK DOOR AND SWITCH FOR REMOTE UNLOCK, REAR LID,
REMOVING AND INSTALLING

The switches for remote/fuel tank door and remote unlock rear trunk lid, cannot be removed separately. The
complete switch unit must be replaced.

Removing

z

Remove door trim. See DOOR TRIM .

z

Disconnect electrical connection.

z

Release switch housing -1- by pressing sideways on locking tabs (arrows) and remove from door trim.

CAUTION:

z

Switch off all electrical consumers.

z

Switch ignition off and remove ignition key.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Lights, Switches - Interior, Anti-Theft - New Beetle



Fig. 6: Removing Switch Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Insert switch -1- into door trim and engage.

z

Connect electrical connection.

z

Install door trim.

SWITCHES IN CENTER OF INSTRUMENT PANEL, REMOVING AND INSTALLING

Removing and installing is the same procedure for all switches. Procedure for hazard warning light switch -E3-
is described here.

Switch must be pulled out in order to disconnect electrical connector.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Lights, Switches - Interior, Anti-Theft - New Beetle



Special tools and equipment

Wood or plastic wedge

Removing

z

Protect instrument panel and adjacent switches with adhesive tape if necessary.

z

Press in adjacent switch and carefully pry out switch using flat plastic wedge or screwdriver.

Fig. 7: Press Adjacent Instrument Panel Switch
Courtesy of VOLKSWAGEN OF AMERICA, INC.

CAUTION:

z

Switch off all electrical consumers.

z

Switch ignition off and remove ignition key.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Lights, Switches - Interior, Anti-Theft - New Beetle
