Fig. 76: Identifying Pressure Line And Suction Hose (vehicles With 2.0 ltr. & 1.9L TDI Engine Without
A/C And Vehicles With 1.8 ltr. Turbo Engine And A/C)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line and suction hose on vehicles with 2.0 ltr. engine and A/C

1. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES

z

Before installing fill with oil. See Note. See POWER STEERING PUMP, RESERVOIR,
HYDRAULIC LINES

2. Suction hose

3. Spring-type clip

4. Pressure line

5. Banjo union bolt

z

38 N.m (28 ft lb)

6. Sealing rings

z

Always replace

7. Lock nut

8. Mounting bracket

9. Hex bolt

z

22 N.m (16 ft lb)

10. Hex bolt

z

40 N.m (30 ft lb)

11. Mounting bracket

12. Cylinder block

NOTE:

The following list refers to items in Fig. 77 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 77: Identifying Pressure Line And Suction Hose (2.0 ltr. Engine And A/C)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line and suction hose on vehicles with unit injector TDI engine

1. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES

z

Before installing fill with oil Note. See POWER STEERING PUMP, RESERVOIR,
HYDRAULIC LINES

2. Banjo union bolt

z

38 N.m (28 ft lb)

3. Sealing rings

z

Always replace

4. Pressure line

5. Spring-type clip

6. Sleeve

z

For power steering pumps from the company Kayaba only

7. Hex bolt

z

22 N.m (16.2 ft lb)

8. Clamp

9. Suction hose

10. Cylinder block

11. Mounting bracket

12. Hex bolt

z

40 N.m (30 ft lb)

NOTE:

The following list refers to items in Fig. 78 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



z

M10x25

13. Hex bolt

z

40 N.m (30 ft lb)

z

M8x28

14. Oil filter

15. Transmission

16. Hex bolt

z

38 N.m (28 ft lb)

Fig. 78: Identifying Pressure Line And Suction Hose (Vehicles With Unit Injector 1.9L TDI Engine)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line on 5-speed manual transmission 02J

1. Pressure line

2. Speed nut

3. Mounting bracket

4. Hex bolt

z

22 N.m (16 ft lb)

5. Mounting bracket

6. Pressure hose

NOTE:

The following list refers to items in Fig. 79 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 79: Identifying Securing Pressure Line On 5-Speed Manual Transmission 02J
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line on 6-speed manual transmission 02M

1. Pressure line

2. Hex nut

z

22 N.m (16 ft lb)

3. Mounting bracket

4. Securing bolt on starter

5. Hex bolt

z

22 N.m (16 ft lb)

6. Mounting bracket

7. Hex nut

z

22 N.m (16 ft lb)

8. Mounting bracket

NOTE:

The following list refers to items in Fig. 80 .
