2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 6: Removing Universal Joint Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing steering column before removal

An assembly aid is required so that the upper and lower parts of the steering column do not pull apart when
pulling off steering gear.

If the upper and lower parts of the steering column are pulled too far apart or pushed too close together
the splines will be separated .

It is possible that rattling noises may occur later on if splines are not in their original installation
position .

z

Push or pull steering column together or apart until the hole is visible.

z

Insert for example a clip in the hole -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 7: Inserting Clip In Steering Column Hole
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with the steering column from the company Nacam up to 01.00



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



z

Remove nut -3-.

z

Pull out bolt -1-.

z

Remove bolts -2- and take out steering column.

1. Hex bolt

2. Hex bolt

z

22 N.m (16.2 ft lb)

3. Hex nut

z

10 N.m (7 ft lb)

4. Cross member for steering column

NOTE:

The following list refers to items in Fig. 8 .
