4. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES

z

Before installing fill with oil Note. See POWER STEERING PUMP, RESERVOIR,
HYDRAULIC LINES

5. Sleeve

z

Power steering pumps for the company Kayaba only

6. Clamp

7. Hexagon bolt

z

22 N.m (16 ft lb)

8. Spring-type clip

9. Suction hose

10. Mounting bracket

z

On the cylinder block

11. Mounting bracket

12. Hex bolt

z

40 N.m (30 ft lb)



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 85: Identifying Pressure Line And Suction Hose
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line and suction hose on the automatic transmission 09G

1. Automatic transmission

2. Twin bolt

z

40 N.m (30 ft lb)

3. To reservoir

4. Hex nut

z

22 N.m (16 ft lb)

5. Return hose

NOTE:

The following list refers to items in Fig. 86 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



6. From the steering gear

7. From the power steering pump

8. Pressure line

9. Hex bolt

z

22 N.m (16 ft lb)

10. To steering gear

Fig. 86: Identifying Pressure Line And Suction Hose On Automatic Transmission 09G
Courtesy of VOLKSWAGEN OF AMERICA, INC.

POWER STEERING PUMP IN LOWER SECTION, ASSEMBLY OVERVIEW

Vehicles with power steering pump in lower section

1. Mounting bracket

NOTE:

The following list refers to items in Fig. 87 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



2. Hex bolt

z

25 N.m (18 ft lb)

3. Banjo union bolt

z

38 N.m (28 ft lb)

4. Pressure line

5. Sealing rings

z

Always replace

6. Suction hose

7. Spring-type clip

8. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES

z

Before installing fill with oil Note POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES

9. Belt pulley

10. Hexsocket head bolt

z

25 N.m (18 ft lb)

11. Ribbed belt

z

Mark the direction of travel with a crayon or marker before removing. Reinstalling a used belt in
the opposite direction could damage the belt.

z

When installing the belt, make sure that it is correctly seated in the pulleys.

z

Application. See Parts catalog

z

Removing and belt routing

See RIBBED BELT, REMOVING AND INSTALLING in appropriate ENGINE MECHANICAL
article

z

Checking condition

See CHECKING CONDITION in RIBBED V-BELT, CHECKING CONDITION article

12. Tensioner for ribbed belt
