z

Clamp off suction line with hose clamps -3094-.

z

Open spring-type clip -1- and disconnect suction line.

Fig. 70: Disconnecting Power Steering Pump Suction Line (Vehicles With Power Steering Pump In
Upper Section)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew banjo union bolt -2-.

{

Seal pressure line/hose with a plastic bag or similar.

z

Remove hex bolts -1- and -2-.

z

Remove pump.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 71: Removing Power Steering Pump Bolts (Vehicles With Power Steering Pump In Upper
Section)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Fill power steering pump with hydraulic oil.

Fill pump with oil via suction union.

z

Turn hub by hand until oil emits from pressure side.

z

Install power steering pump into bracket and tighten bolts to 25 N.m (18 ft lb).

z

Install suction line and spring-type clip.

The mark -arrow A- must align with casting seam -arrow-

The spring-type clip must close off mark -arrow B-.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 72: Installing Suction Line And Spring-Type Clip (Vehicles With Power Steering Pump In
Upper Section)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install new sealing rings onto Banjo union bolt.

z

Tighten Banjo union bolt to 38 N.m (28 ft lb).

The remainder of the installation is the reverse of removal.

POWER STEERING PUMP WITH HYDRAULIC LINES/HOSES, ASSEMBLY OVERVIEW

I. Vehicles with power steering pump in upper section

II. Vehicles with power steering pump in lower section

NOTE:

The following list refers to items in Fig. 73 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



1. Reservoir

Disassembling and assembling instructions. See DISASSEMBLING AND ASSEMBLING
RESERVOIR

2. Securing pressure hose/line

Vehicles with TDI engine and A/C

Disassembling and assembling instructions. See SECURING PRESSURE LINE AND SUCTION
HOSE ON VEHICLES WITH TDI ENGINE AND A/C

3. Pressure hose/line mounting

Vehicles with 2.0 ltr. and TDI engine without A/C

Vehicles with 1.8 ltr. turbo engine with A/C

Disassembling and assembling instructions. See SECURING PRESSURE LINE AND SUCTION
HOSE ON VEHICLES WITH 2.0 LTR., & TDI ENGINE WITHOUT A/C AND VEHICLES
WITH 1.8 LTR. TURBO ENGINE AND A/C

Vehicles with 2.0 ltr. engine with A/C

Vehicles with 1.8 ltr. turbo engine without A/C

Disassembling and assembling instructions. See SECURING PRESSURE LINE AND SUCTION
HOSE ON VEHICLES WITH 2.0 LTR. ENGINE AND A/C .

4. Securing suction hose

5. Pressure hose/line mounting

On 5-speed manual - transmission 02J

Disassembling and assembling instructions. See SECURING PRESSURE LINE ON 5-SPEED
MANUAL TRANSMISSION 02J .

On 6-speed manual transmission 02M

Disassembling and assembling instructions. See SECURING PRESSURE LINE ON 6-SPEED
MANUAL TRANSMISSION 02M .

6. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES .
