z

VAS 5024 Assembly pliers

Fig. 50: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove engine cover -arrows-.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 51: Removing Engine Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Clamp return hose with hose clamp 3094.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 52: Clamping Return Hose Clamp With Hose Clamp 3094
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Clamp suction hose with hose clamp 3094.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 53: Clamping Suction Hose Using Hose Clamp 3094.
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Place drip tray underneath.

z

Disconnect pump pressure line.

Connecting pressure gauge V.A.G 1402

1. V.A.G 1402 Pressure gauge

2. V.A.G 1402 Hose from pressure gauge

3. V.A.G 1402/6 Hose from adapter set

4. V.A.G 1402/1 A Adapter

5. Oil seal

NOTE:

The following list refers to items in Fig. 54 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
