13. Return line

14. Steering gear

z

Removing and installing. See POWER STEERING, SERVICING

15. Mounting bracket with rubber mounting

z

Replace if threads in welded nut are damaged

16. Heat shield

17. Self-locking hex nut

z

45 N.m (33 ft lb)

18. Hex nut

z

22 N.m (16 ft lb)

Fig. 35: Exploded View Of Power Steering Gear Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



TIE ROD, REMOVING AND INSTALLING

Special tools and equipment

z

VW 313 Support clamp

z

V.A.G 1275 Pliers

z

V.A.G 1332 Torque wrench

z

V.A.G 1332/5 Open jaw insert, 34 mm AF

z

T10108 Transmission bracket



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 36: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

The tie rods can only be removed/installed with the steering gear removed.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Removing and installing power steering gear. See POWER STEERING, SERVICING

z

Seal line/hose connections on power steering gear if not already done.

z

Clean outside of power steering gear in surrounding area of the boot.

z

Open hose clamps and push boot back.

z

Clamp steering gear on transmission holder T10108 and unscrew tie rod from coupling rod.

z

To determine center position on the rack. See CENTER POSITION ON STEERING RACK,
DETERMINING

Fig. 37: Removing Tie Rod From Coupling Rod
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order.

Tightening torque:

NOTE:

To clamp steering gear, use hole "5" and the corresponding hole lying opposite
in transmission holder T10108.
