Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

When the center position is reached, quickly disconnect the electrical connector.

z

Insert motor onto the fresh air/recirculating air shaft -1-. See Fig. 2

z

Turn motor in direction of -arrow A-.

z

Install mounting screw.

z

Reconnect electrical connector.

Fig. 26: Inserting Motor Onto Fresh Air/Recirculating Air Shaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.

HEATING AND VENTILATION CONTROLS, ASSEMBLY

1. Heating and ventilation controls

z

With fresh air blower switch -E9-

z

With switch for fresh air blower and recirculated air -E184-

z

Removing and installing, See Heating and ventilation controls, removing and installing .

2. Illumination filter

3. Trim panel

4. Fresh air control lever light -L16-

z

12V, 1.2W

5. Rotary control

NOTE:

If it is difficult to align and fit the motor to shaft -1-, remove fresh air
blower -V2- and position flap/shaft as required. See Fig. 2 .

NOTE:

The following list refers to items in Fig. 27 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



z

For blower speed

z

To remove: Use pliers with suitable plastic or rubber protection on jaws

6. Rotary control

z

For air distribution

z

To remove: Use pliers with suitable plastic or rubber protection on jaws

7. Rotary control

z

For interior temperature

z

To remove: Use pliers with suitable plastic or rubber protection on jaws

Fig. 27: Identifying Components Of Heating And Ventilation Controls Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

HEATING AND VENTILATION CABLES, INSTALLING AND ADJUSTING

NOTE:

z

Cable sleeve ends are color coded.

z

Check cables before installing. Replace binding or damaged cables.

z

Attach cables to removed controls first and then attach to levers at heating
and ventilation unit.

z

All air flaps must audibly move onto end stops when turning controls.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



Fig. 28: Installing Heating And Ventilation Cables
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Central flap cable

z

From air distribution rotary control to central flap

z

Cable sleeve marking: Yellow

z

Installing and adjusting, See INSTALLING & Adjusting Central Flap Cable

2. Footwell/defrost flap cable

z

From air distribution rotary control to footwell/defrost flap

z

Cable sleeve marking: Green

z

Removing:

„

Remove heating and ventilation controls, See Heating and ventilation controls, removing
and installing

„

Unclip cable from controls

„

Remove steering column trim.

See TRIM UNDER STEERING COLUMN, REMOVING .

„

Unclip cable at heating and ventilation unit.

z

Installing and adjusting, See Installing & Adjusting Footwell/Defrost Flap Cable

3. Heating and ventilation controls

z

Removing and installing, See Heating and ventilation controls, removing and installing

4. Temperature flap cable

z

From temperature rotary control to temperature flap

z

Cable sleeve marking: Beige

NOTE:

The following list refers to items in Fig. 28 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



z

Installing and adjusting, See Adjusting Temperature Flap Cable

Adjusting Temperature Flap Cable

Cable sleeve marking: Beige

Fig. 29: Installing Temperature Flap Cable
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Prerequisites:

z

Heating and ventilation controls are installed.

z

Connecting duct removed, See Connecting duct, removing .

z

Turn temperature rotary control knob to left onto stop.

z

Attach center wire of cable -1- to the temperature flap lever -2-. See Fig. 29 .

z

Push temperature flap lever -2- onto stop -arrow A- and secure outer cable -1- with clip -3-.

z

Turn temperature rotary control knob to left and right onto stops.

When turning the rotary control knob both end stops must be reached.

Installing & Adjusting Footwell/Defrost Flap Cable

Cable sleeve marking: Green



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle
