Volkswagen New Beetle. Manual - part 2021

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Components of dust and pollen filter:

1. Frame

2. Filter element

3. Plastic nut, 2.5 N.m (20 in lb)

4. Filter housing with seal

Removing

z

Push center cover -1- forward -arrow A- and lift up to remove.

Fig. 7: Pushing Center Cover Forward A- And Lifting Up To Remove
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove screws -arrows-. See Fig. 8 .

z

Lift right plenum panel cover -1- and remove from clips at front and rear edge. See Fig. 8 .

z

Pull cover -1- toward center of vehicle and out of retainer in A-pillar to remove.

NOTE:

The following list refers to items in Fig. 6 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



Fig. 8: Lifting Right Plenum Panel Cover And Removing From Clips At Front And Rear Edge
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove screws -arrows- and remove right closeout panel -1-.

Fig. 9: Removing Screws And Remove Right Closeout Panel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove rubber grommet -1-.

z

Press tabs of filter housing in direction of -arrow-.

z

Remove filter element with frame in upward direction -arrow A-.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



Fig. 10: Removing Filter Element With Frame In Upward Direction
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Guide frame -1- into first slot on left and right sides of new filter element.

z

Press frame with filter into housing -2- and engage retainers.

AIR OUTLETS, REMOVING

Side window air outlets, removing

z

Carefully remove air outlet -1- with needle nose pliers.

Fig. 11: Removing Air Outlet With Needle Nose Pliers

NOTE:

To prevent damage to air outlets, use needle nose pliers with suitable plastic or
rubber protection on jaws.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

Side air outlets, removing

z

Carefully remove air outlet -1- with needle nose pliers as indicated.

Fig. 12: Removing Air Outlet With Needle Nose Pliers (Side Outlet)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Center air outlet console, removing

First do the following:

z

Remove radio.

See RADIO, REMOVING AND INSTALLING .

z

Push center cover -1- forward -arrow A- and lift up to remove.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle
