Fig. 26: Checking A/C Refrigerant System For Leaks
Courtesy of VOLKSWAGEN OF AMERICA, INC.

A/C REFRIGERANT SYSTEM, CAPACITIES

REFRIGERANT R-134A, CAPACITY

REFRIGERANT R-134a CAPACITY

Obtain R-134a refrigerant from a local A/C supplier under one of the following names:

z

R-134a

z

Tetrafluoroethane

Model

Quantity

New Beetle

700 g +/- 50 g (24.7 oz +/- 1.8 oz)



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



z

CH

2

 F CF

3



z

H-FKW 134a

z

SUVA(R) TRANS A/C

z

ARCTON(R) 134a

REFRIGERANT (PAG) OIL R-134A, CAPACITY

REFRIGERANT OIL R-134A, CAPACITY

Replacement A/C compressors supplied by the Parts Department are filled with 135 cc (fl. oz.) of refrigerant
oil. This is the total A/C system refrigerant oil capacity.

REFRIGERANT (PAG) OIL R-134A, DISTRIBUTION

The total refrigerant oil quantity is distributed in the refrigerant circuit as follows:

Compressor approx.50%

Compressor approx. 10%

Suction pipe approx. 10%

Discharge pipe - (Not available)

Evaporator approx. 20%

Receiver drier approx. 10%

REFRIGERANT (PAG) OIL R-134A, IDENTIFICATION

Use only the correct type of refrigerant oil (PAG oil) specified for use with R-134a and compressor type.

REFRIGERANT OIL R-134A, IDENTIFICATION

NOTE:

R-134a refrigerant is packaged in different containers. Some are used only for
commercial applications which are sold in cylinders using a 1/4" flare fitting.
This does not connect to the vehicle fittings and servicing equipment. Use only
R-134a which come in containers having the correct type of service fitting.

Model

Total system capacity

New Beetle

135 cc (4.6fl. oz.)

NOTE:

When replacing refrigerant circuit components, fill an appropriate amount of
refrigerant oil (as indicated above) into the new part before installation.

Compressor

Refrigerant oil Part No.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



HEATING AND A/C CONTROLS/MECHANICAL COMPONENTS, SERVICING

COMPONENTS IN PASSENGER COMPARTMENT, SERVICING

Sanden SD7-V16

G 052 154 A2

CAUTION: Part numbers are for reference only. Always check with for Parts

Department for latest parts information.

CAUTION: Before beginning repairs on the electrical system:

z

Obtain the anti-theft radio security code.

z

Switch the ignition off.

z

Disconnect the battery Ground (GND) strap.

z

After reconnecting battery, re-code and check operation of anti-theft
radio. Also check operation of clock and power windows according
to service information and/or Owner's Manual.

z

Immediately plug open connections on A/C components to prevent
dirt and moisture contamination.

NOTE:

z

Before carrying out any work on the A/C refrigerant system, refer to A/C
refrigerant system safety measures, See A/C refrigerant system .

z

System components identified with an * must only be serviced or replaced
after discharging refrigerant system. Use Kent Moore ACR4 or equivalent.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Fig. 27: Heating And A/C Controls/Mechanical Components (Passenger Compartment)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Heating and A/C controls

z

With A/C switch -E35-

z

With fresh air blower switch -E9-

z

With switch for fresh air blower and recirculated air -E184-

NOTE:

The following list refers to items in Fig. 27 .
