Fig. 8: Connecting VAG1598/31 Test Box At Control Module Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

When harness connectors are disconnected from the Engine Control Module (ECM) or the battery is
disconnected, all adaptation values in the control module are erased. DTC memory content will remain intact
however. If the engine is started after this, rough, uneven idle can result. In this case, the readiness code must be
generated again, see READINESS CODE, GENERATING .

Check Malfunction Indicator Lamp (MIL) in instrument cluster

Meaning of exhaust MIL

The Malfunction Indicator Lamp (MIL) lights up when exhaust relevant malfunctions are recognized by the
Engine Control Module (ECM).

Component location of exhaust MIL

Fig. 9: Identifying ECM Harness Connector Terminals



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Blinking: There is a malfunction that causes damage to the catalytic converter in this driving condition. In
this case, vehicle must only be driven at reduced performance!

z

Continuously lit: There is a malfunction that causes increased emissions. Check DTC memory for
Motronic control module.

z

DTC memory must still be checked if there are drivability problems or customer complaints and the MIL
is not lit, since malfunctions can be stored without causing the MIL to light immediately.

Recommended special tools and equipment

z

VAG1526 multimeter or VAG1715 multimeter

z

VAG1594 connector test kit

z

Wiring diagram

Test requirement

z

The respective fuses of Malfunction Indicator Lamp (MIL) -K83- must be OK. Fuse holder is located
behind access panel at far left end of dash.

Fig. 10: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test sequence

z

Switch on ignition:

NOTE:

The Malfunction Indicator Lamp (MIL) can blink or remain lit continuously. DTC
memory must be checked in each case, see DIAGNOSTIC MODE 3: CHECK DTC
MEMORY .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



exhaust MIL must light up.

If exhaust MIL does not light up when ignition is switched on:

z

Switch ignition off.

z

Check wire from ECM to exhaust MIL as follows:

z

Connect test box to control module wiring harness, see CONNECT TEST BOX FOR WIRING TEST .

z

Bridge sockets 2+47 of test box with the respective adapter cables.

z

Switch on ignition:

exhaust MIL must light up.

If Malfunction Indicator Lamp (MIL) does not light up:

z

Switch ignition off.

z

Remove instrument cluster:

See INSTRUMENT CLUSTER, REMOVING AND INSTALLING

z

Check wire connection from Engine Control Module (ECM) to Malfunction Indicator Lamp (MIL) -K83-
according to wiring diagram.

z

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .

z

Generate readiness code, see READINESS CODE, GENERATING .

If no malfunctions are detected in wire from Engine Control Module (ECM) to Malfunction Indicator
Lamp (MIL):

z

Replace Motronic Engine Control Module (ECM) -J220-, see REPLACING ENGINE CONTROL
MODULE (ECM) .

If exhaust MIL lights up when ignition is switched on:

z

Start engine and let run at idle:

Exhaust MIL must

go out after a few seconds.

If Malfunction Indicator Lamp (MIL) does not go out:

z

Switch ignition off.

z

Remove instrument cluster:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



See INSTRUMENT CLUSTER, REMOVING AND INSTALLING

z

Connect test box to control module wiring harness, see CONNECT TEST BOX FOR WIRING TEST .

z

Check wire connection between test box socket 47 and instrument cluster for short circuit to Ground
(GND) according to wiring diagram.

z

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .

z

Generate readiness code, see READINESS CODE, GENERATING .

If no malfunctions are detected in wire from Engine Control Module (ECM) to Malfunction Indicator Lamp
(MIL):

z

Replace Motronic Engine Control Module (ECM) -J220-, see REPLACING ENGINE CONTROL
MODULE (ECM) .

SELECT DIAGNOSTIC MODE

Recommended special tools and equipment:

z

VAS 5052 Vehicle Diagnostic and Information System with

z

VAS 5052/3 diagnostic cable

Fig. 11: Identifying VAS 5052 Vehicle Diagnostic And Information System
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Address word 33 - On-Board Diagnostic (OBD)

Function

Via the diagnostic tester, different diagnostic modes can be selected under "address word 33 - On-Board
Diagnostic (OBD)".
