3. Pressure regulator valve

z

For crankcase ventilation

4. Connection hose

z

from deceleration shut-off valve to upper air guide pipe

5. to crankcase breather valve

6. From air filter

7. upper air guide pipe

z

note installation position of heat shield mat

8. Bracket

9. 25 Nm

10. 10 Nm

11. from turbocharger exhaust tube

12. Connection hose

13. Connection hose

z

to vacuum diaphragm for boost pressure regulator valve

14. Retaining clip

z

Check for secure fitting

15. O-ring

z

replace

16. Intake hose

z

to intake tube of turbocharger

17. Wastegate Bypass Regulator Valve -N75-*

z

Valve is activated (pulsed) by the Engine Control Module (ECM)

z

Closed when no voltage present, limits charge pressure

z

Checking, see WASTEGATE BYPASS REGULATOR VALVE, CHECKING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



Fig. 2: Exploded View Of Turbocharger With Attachments (Part II - Engine Code APH)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Part II

Vehicles with engine code AWP, AWV

The following list pertains to Fig. 3 .

1. Pressure regulator valve

z

For crankcase ventilation

2. to crankcase breather valve

3. Deceleration shut-off valve



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



z

Checking, see DECELERATION SHUT-OFF VALVE, CHECKING

4. Connection hose

z

To Recirculating valve for turbocharger -N249-*

5. Connection hose

z

from deceleration shut-off valve to upper air guide pipe

6. From air filter

7. upper air guide pipe

z

note installation position of heat shield mat

z

Vehicles with engine code AWP, AWV with quick -release connection (with O-ring and retaining
clip)

8. Bracket

9. 40 Nm

10. 25 Nm

11. to connection hose for lower connection sleeve/charge air cooler

12. O-ring

z

replace

13. Retaining clip

z

Check for secure fitting

14. 10 Nm

15. from turbocharger exhaust tube

16. Connection hose

17. Connection hose

z

to vacuum diaphragm for boost pressure regulator valve

18. Retaining clip

z

Check for secure fitting

19. O-ring

z

replace

20. Intake hose

z

to intake tube of turbocharger

21. Connection hose

z

To suction jet pump

22. Wastegate Bypass Regulator Valve -N75-

z

Valve is activated (pulsed) by the Engine Control Module (ECM)

z

Closed when no voltage present, limits charge pressure

z

Checking, see WASTEGATE BYPASS REGULATOR VALVE, CHECKING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



Fig. 3: Exploded View Of Turbocharger With Attachments (Part II - Engine Code AWP, AWV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Parts of charge air cooler, removing and installing

The following list pertains to Fig. 4 .

1. Air duct

2. 10 Nm

NOTE:

z

All hose connections are secured with clamps.

z

Charge air system must be properly sealed.

z

Note assembly markings at hoses and components during installation.

z

Note installation position of heat shield mats
