Fig. 34: Identifying Special Tools And Testing Equipments (Engine Codes AEG, AVH AND AZG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Fuel pump delivery rate OK. See FUEL PUMP, CHECKING

Work sequence

z

Remove fuse 28 (fuel pump) from fuse holder.

WARNING:

Fuel system is under pressure! Before opening the system place a
cloth around the connection. Then release pressure by carefully
loosening the connection.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 35: Removing Fuse 28 (Fuel Pump) From Fuse Holder
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull off supply line/hose -1- and collect leaking fuel with a cloth.

NOTE:

Fuse hold is behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 36: Disconnecting Fuel Supply Line/Hoses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect pressure gauge V.A.G 1318 using adapters V.A.G 1318/10,/11 and/16.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 37: Connecting Pressure Gauge V.A.G 1318 Using Adapters V.A.G 1318/10/11/16 For
Measuring Fuel Pressure
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Open shut-off tap on pressure gauge. Handle points in direction of flow.

z

Reinstall fuse 28 (fuel pump) in fuse holder.

z

Start engine and run at idling speed.

z

Measure fuel pressure.

z

Specification: Approx. 2.5 bar

z

Pull vacuum hose -1- off fuel pressure regulator -2-.

Fig. 38: Removing Vacuum Hoses From Fuel Pressure Regulator
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Fuel pressure must increase to approx. 3.0 bar
