Fig. 12: Exploded View Of Intake Manifold Lower Parts (Engine Code BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine code BEV



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



1. Wiring guide

z

Clipped onto fuel distributor

2. Fuel rail

z

With breather valve item -10- for fuel system

3. Supply union

4. O-ring

5. Injectors -N30-...-N33-

z

Checking injectors for leaks and quantity injected. See COMPONENTS, CHECKING

6. Retaining clip

z

Check for secure seating

7. 20 N.m

8. Seal

z

Replace

9. Intake manifold lower part

10. Breather valve

z

Bleeding fuel system. See FUEL SYSTEM, BLEEDING

11. Cap

z

For breather valve

12. 10 N.m

NOTE:

The following list refers to items in Fig. 13 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 13: Exploded View Of Intake Manifold Lower Parts (Engine Code BEV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine code BGD

1. Fuel rail

z

With breather valve item -3- for fuel system

2. Cap

z

For breather valve

3. Breather valve

z

Bleeding fuel system. See FUEL SYSTEM, BLEEDING

4. Cable guide

NOTE:

The following list refers to items in Fig. 14 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Clipped onto fuel rail

5. Seal

z

Replace

6. 10 N.m

7. Intake manifold lower part

z

With variable intake manifold change-over

8. 3 N.m

9. To vacuum positioning element

z

On front side of intake manifold lower part

10. Intake Manifold Tuning (IMT) valve -N261-

11. 5 N.m

12. Washer

13. 25 N.m

14. From intake manifold upper part

z

See Fig. 9 , item -12-

15. Seal

z

Replace

16. Supply union

17. O-ring

18. Injectors -N30-...-N33-

z

Checking injectors for leaks and quantity injected. See COMPONENTS, CHECKING

19. Retaining clip

z

Check for secure seating
