2. Ignition coil with power output stage (-N70-, -N127-, -N291-, -N292-)*

z

Ignition wires connection: HV1 = Cylinder 1HV2 = Cylinder 2HV3 = Cylinder 3HV4 = Cylinder 4

z

Checking. See CHECKING IGNITION COILS WITH POWER OUTPUT STAGES
(VEHICLES WITH ENGINE CODE AVH, AZG, BDC) .

Component location:

z

Vehicles with engine code AVH, AZG. See item 18 in OVERVIEW OF COMPONENT
LOCATIONS (VEHICLES WITH ENGINE CODE AVH, AZG) .

z

Vehicles with engine code BDC. See item 19 in OVERVIEW OF COMPONENT LOCATIONS
(VEHICLES WITH ENGINE CODE BDC) .

3. 10 Nm

4. Connector

z

6-pin

5. Knock Sensor (KS) 1 (G61)*

z

contact surfaces between knock sensor and cylinder block must be free of corrosion, dirt and grease

z

Terminals of sensor and connector are gold-plated

z

Checking. See CHECK KNOCK SENSORS .

Component location:

z

Vehicles with engine code AVH, AZG. See item 27 in OVERVIEW OF COMPONENT
LOCATIONS (VEHICLES WITH ENGINE CODE AVH, AZG) .

z

Vehicles with engine code BDC. See item 25 in OVERVIEW OF COMPONENT LOCATIONS
(VEHICLES WITH ENGINE CODE BDC) .

6. Connector

z

2-pin

z

For Knock Sensor (KS) 1 -G61-

z

before disconnecting, mark allocation of connector to component

z

Terminals of sensor and connector are gold-plated

7. Knock Sensor (KS) 2 (G66)*

z

contact surfaces between knock sensor and cylinder block must be free of corrosion, dirt and grease

z

Terminals of sensor and connector are gold-plated

z

Checking. See CHECK KNOCK SENSORS .

Component location:

z

Vehicles with engine code AVH, AZG. See item 24 in OVERVIEW OF COMPONENT
LOCATIONS (VEHICLES WITH ENGINE CODE AVH, AZG) .

z

Vehicles with engine code BDC. See item 24 in OVERVIEW OF COMPONENT LOCATIONS
(VEHICLES WITH ENGINE CODE BDC) .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



8. Connector

z

2-pin

z

For Knock Sensor (KS) 2 -G66-

z

before disconnecting, mark allocation of connector to component

z

Terminals of sensor and connector are gold-plated

9. Connector

z

2-pin

z

For Knock Sensor (KS) 1 -G61-

z

before disconnecting, mark allocation of connector to component

z

Terminals of sensor and connector are gold-plated

10. Spark plug, 30 Nm

z

Type and spark plug gap. See TEST DATA, SPARK PLUGS .

11. Connector

z

3-pin

z

For Camshaft Position (CMP) sensor 2 -G40-

z

Terminals of sensor and connector are gold-plated

12. 10 Nm

13. 100 Nm

z

Use Retainer (3415) when loosening or tightening

14. Camshaft gear

z

with trigger wheel for Camshaft Position (CMP) Sensor -G40-

15. Camshaft Position (CMP) sensor (G40)*

z

Terminals of sensor and connector are gold-plated

z

Checking. See CHECK CAMSHAFT POSITION (CMP) SENSOR .

Component location:

z

Vehicles with engine code AVH, AZG. See item 2 in OVERVIEW OF COMPONENT
LOCATIONS (VEHICLES WITH ENGINE CODE AVH, AZG) .

z

Vehicles with engine code BDC. See item 4 in OVERVIEW OF COMPONENT LOCATIONS
(VEHICLES WITH ENGINE CODE BDC) .

16. Bracket

z

for Camshaft Position (CMP) sensor



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



Fig. 2: Identifying Parts Of Ignition System (Vehicles With Engine Code AVH, AZG, BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Safety precautions

If test and measuring equipment is required during road test, note the following:

z

Test equipment must always be secured to the rear seat and operated from there by a second person.

If test and measuring equipment is operated from the passenger seat, the person seated there could be
injured in the event of an accident involving deployment of the passenger -side airbag.

To reduce the risk of personal injury and/or damage to the fuel injection and ignition system, always
observe the following:

z

Do not touch or disconnect ignition wires when engine is running or turning at starting RPM.

z

Only disconnect and reconnect wires for injection and ignition system, including test leads, when ignition
is switched off.

z

If engine is to be cranked at starting RPM without starting, e.g. for a compression test:

WARNING:

Observe the following for all installations, especially in engine
compartment due to lack of room:

z

Route lines of all types (e.g. for fuel, hydraulic, EVAP canister
system, coolant and refrigerant, brake fluid, vacuum) and electrical
wiring so that the original path is followed.

z

Watch for sufficient clearance to all moving or hot components.

z

Fuel system is under pressure! Before opening system, place rags
around the connection point. Then release pressure by carefully
loosening connection.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



Vehicles with engine code AEG

z

Disconnect 4-pin connector from Ignition Coil -N152- (arrow).

Fig. 3: Disconnecting 4-Pin Connector From Ignition Coil -N152- (AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with engine code AVH, AZG, BDC

z

Disconnect the 6-pin connector from the power output stage for ignition coils (arrow).

Fig. 4: Disconnecting 6-Pin Connector From Power Output Stage For Ignition Coils (AVH, AZG,
BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all vehicles

z

Remove fuse 32 from fuse holder.
