Fig. 7: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

Parking brake must be engaged or else daylight driving lights will be switched on.

z

Ground (GND) connections between engine and chassis must be OK.

Test sequence

z

Disconnect 3-pin connector -1- from Camshaft Position (CMP) sensor -2-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



Fig. 8: Disconnecting 3-Pin Connector From Camshaft Position (CMP) Sensor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect multimeter to terminal 1 (B+) and 3 (Ground -GND-) of the respective connector for Camshaft
Position (CMP) sensor for voltage measurement.

z

Switch ignition on.

Specified value: at least 4.5 V

z

Switch ignition off.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



If there is no voltage:

z

Connect test box to control module wiring harness, see CONNECT TEST BOX FOR WIRING TEST .

z

Check for open circuits in wires between test box and connector according to wiring diagram.

Terminal 1+socket 98

Terminal 2+socket 86

Terminal 3 + socket 108

Wire resistance: max. 1.5 ohm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



Fig. 9: Identifying CMP Sensor 3-Pin Harness Connector Terminals
