Fig. 1: Exploded View Of Ignition System Components (Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine codes AVH, AZG, BDC, BEV, BGD

1. H.T. cable

z

4...8 kohm

z

With suppression connector and spark plug connector

z

Check for continuity

z

Pull spark plug connector off with T10112.

NOTE:

The following list refers to items in Fig. 2 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



2. Ignition coils with final output stages -N70-, -N127-, -N291-, -N292-

z

With marks for H.T. cables: HV1 = Cylinder 1, HV2 = Cylinder 2, HV3 = Cylinder 3, HV4 =
Cylinder 4

3. 10 N.m

4. 6-pin connector

5. Knock Sensor (KS) 1 -G61-

z

Gold plated contacts

z

Location: Cylinder block intake side

6. 2-pin connector

z

For KS 1 -G61-

z

Gold plated contacts

z

Do not interchange

7. Knock Sensor (KS) 2 -G66-

z

Gold plated contacts

z

Next to ignition transformer

8. 2-pin connector

z

For KS2 -G66-

z

Gold plated contacts

z

Do not interchange

9. 20 N.m

z

Torque setting influences the function of knock sensor

10. Spark plug, 25 N.m

z

Type and electrode gap. See TEST DATA, SPARK PLUGS

z

To remove and install pull off connectors for outer injectors

z

Remove and install with 3122 B

11. Connector

z

Gold plated contacts

z

3-pin

12. 10 N.m

13. 100 N.m

z

Use counter support tool 3415 to loosen and tighten

14. Camshaft pulley

z

With rotor for camshaft position sensor

z

Removing and installing. See VALVE GEAR, SERVICING

15. Camshaft Position (CMP) sensor -G40-

16. Retainer

z

For camshaft position sensor



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 2: Exploded View Of Ignition System Components (Engine Code AVH, AZG, BDC, BEV AND BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

SAFETY PRECAUTIONS

To prevent injuries to persons and/or damage to the fuel injection and ignition system, the following must be
observed:

WARNING:

When performing repair work, especially due to the confined conditions
in the engine compartment, pay attention to the following:

z

Route all types of lines (e.g. for fuel, hydraulics, EVAP system,
coolant, refrigerant, brake fluid and vacuum) as well as electrical
wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving or hot components.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Do not touch or disconnect ignition wiring when the engine is running or being turned at starter speed.

z

The ignition must be switched off before connecting or disconnecting injection or ignition system wiring
or tester cables.

z

If the engine is to be turned at starter speed, without starting:

Engine code AEG

z

Disconnect 4-pin harness connector -1- from ignition coil power output stage -2-.
