Test conditions

z

All fuses must be OK. Fuse holder is located behind access panel at far left end of dash.

Fig. 9: Locating Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 V

z

Camshaft Position (CMP) sensor -G40- must be OK, checking, see CAMSHAFT POSITION (CMP)
SENSOR -G40-, CHECKING

z

Engine speed (RPM) sensor must be OK, checking, see ENGINE SPEED (RPM) SENSOR,
CHECKING

Test sequence

z

Disconnect 4-pin connector -2- from ignition coil with power output stage to be checked -1-..

NOTE:

Ignition coils and power output stages are one component and cannot be
replaced individually.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition/Glow plug system, 1.8L AWP, AWV - New Beetle



Fig. 10: Disconnecting 4-Pin Connector From Ignition Coil
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking voltage supply

z

Using multimeter and adapter cables from V.A.G 1594 C measure supply voltage between terminals 1 +
2 and 1 + 4 of disconnected connector.

Fig. 11: Identifying Ignition Coil 4-Pin Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Switch on ignition.

Specification: Min. 11.5 V

z

Switch off ignition.

If no voltage is present:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition/Glow plug system, 1.8L AWP, AWV - New Beetle



z

Check wiring for open circuit between 4 -pin connector terminal 1 and current supply relay for Motronic
(main relay) using Electrical Wiring Diagrams.

Wire resistance: max. 1.5 ohm

Fig. 12: Identifying Ignition Coil 4-Pin Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring between 4 -pin connector and Ground (GND) for open circuit according to Electrical
Wiring Diagrams.

z

Terminal 2 and Ground (GND)

z

Terminal 4 and Ground (GND)

Wire resistance: max. 1.5 ohm

If there is no malfunction in the supply voltage:

z

Check activation, see CHECKING ACTIVATION .

Checking activation

z

Pull fuse No. 32 out of fuse holder.

WARNING:

During the following test do not touch the connecting parts of the ignition
coils or test cables.

NOTE:

Removing fuse 32 interrupts the voltage supply to the fuel injectors. Fuse
holder is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition/Glow plug system, 1.8L AWP, AWV - New Beetle



Fig. 13: Locating Fuse 32
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect V.A.G 1527 B voltage tester with adapter cables from V.A.G 1594 C to terminals of
disconnected connector

Fig. 14: Identifying Ignition Coil 4-Pin Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Contacts 2 + 3

z

Operate starter and check ignition signal from Engine Control Module.

LED must flicker

z

Switch off ignition.

When the LED flickers and the supply voltage is OK:

z

Using removal tool T40039, replace ignition coil with power output stage, see item 2 .
