Fig. 25: VAG 1551 Scan Tool Display - Checking Misfiring Recognition (3 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Increase engine speed until display field 4 indicates status -Misfire recognition activated -.

z

Check total number of misfires in display zone 3.

DISPLAY GROUP 14: IGNITION, MISFIRE RECOGNITION

If the specification is not obtained, see EVALUATING DISPLAY GROUP 14, DISPLAY ZONE 3 -
TOTAL NUMBER OF CATALYST DAMAGING MISFIRES , Evaluating display group 14

If the specifications are obtained:

z

Press key.

z

Press keys 0 and 6 for "End output" function and confirm input with Q key.

z

Switch off ignition.

If the specifications are not attained:

z

Change to display group 15 as follows:

z

Press key 3 ((V.A.G 1551) or key UPARROW (V.A.G 1552).



Display zones

1

2

3

4

Display group 14: ignition, misfire recognition
Display

xxxx RPM

xxx.x %

xxx

Activated Blocked

Indicated

Engine speed (in 40

steps)

Engine

load

Catalyst damaging misfires

(Total)

Misfire recognition

status

Working
range

0-6800 RPM

0.0 -100.0

%

0-65000

-

Specification

-

>14.0 %

0

activated



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



Indicated on display (1-4 Display zones)

Fig. 26: VAG 1551 Scan Tool Display - Checking Misfiring Recognition (4 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Increase engine speed until display field 4 indicates status - Misfire recognition activated -.

z

Check misfiring in display zones 1 -3.

DISPLAY GROUP 15: IGNITION, MISFIRE RECOGNITION

If the specification is not obtained, see EVALUATING DISPLAY GROUP 14, DISPLAY ZONE 3 -
TOTAL NUMBER OF CATALYST DAMAGING MISFIRES , Evaluating display groups 15 and 16

If the specifications are obtained:

z

Change to display group 16 as follows:

z

Press key 3 ((V.A.G 1551) or key UPARROW (V.A.G 1552).

Indicated on display (1 and 4 Display zones)



Display zones

1

2

3

4

Display group 15: ignition, misfire recognition
Display

xxx

xxx

xxx

Activated Blocked

Indicated

Catalyst damaging

misfires Cyl. 1

Catalyst damaging

misfires Cyl. 2

Catalyst damaging

misfires Cyl. 3

Misfire

recognition status

Working
range

0-65000

0-65000

0-65000

-

Specification

0

0

0

activated



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



Fig. 27: VAG 1551 Scan Tool Display - Checking Misfiring Recognition (5 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Increase engine speed until display field 4 indicates status -Misfire recognition activated -.

z

Check misfiring in display zone 1.

DISPLAY GROUP 16: MISFIRING RECOGNITION

If the specification is not obtained, see EVALUATING DISPLAY GROUP 14, DISPLAY ZONE 3 -
TOTAL NUMBER OF CATALYST DAMAGING MISFIRES , Evaluating display groups 15 and 16

z

Press --> key.

z

Press keys 0 and 6 for "End output" function and confirm input with Q key.

z

Switch off ignition.

Evaluating display group 14, display zone 3 - total number of catalyst damaging misfires

EVALUATING DISPLAY GROUP 14, DISPLAY ZONE 3 - TOTAL NUMBER OF CATALYST
DAMAGING MISFIRES



Display zones

1

2 3

4

Display group 16: misfiring recognition
Display

xxx

- -

Active Blocked

Indicated

Exhaust damaging misfires Cyl. 4

- -

Misfire status recognition

Working range

0-65000

- -

-

Specification

0

- -

activated

Appears on
display

Possible malfunction cause

Malfunction elimination

Larger 0

z

Spark plug malfunctioning

z

Ignition coil

z

Check spark plugs, see IGNITION SYSTEM,

SERVICING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



Evaluating display group 15 display zones 1 to 4/display group 16 display zones 1 and 4 - catalyst damaging misfires Cyl. 1 to Cyl.
4

EVALUATING DISPLAY GROUP 15 DISPLAY ZONES 1 TO 4/DISPLAY GROUP 16 DISPLAY
ZONES 1 AND 4 - CATALYST DAMAGING MISFIRES CYL. 1 TO CYL. 4

malfunctioning

z

Power output stage for

ignition coil

malfunctioning

z

Check ignition coils with power output stage, see
IGNITION COILS WITH POWER OUTPUT

STAGE, CHECKING

z

Injector malfunctioning

z

Check injectors, see FUEL INJECTORS,

CHECKING

Appears on
display

Possible malfunction cause

Malfunction elimination

Larger 0

z

Spark plug malfunctioning

z

Ignition coil

malfunctioning

z

Power output stage for

ignition coil

malfunctioning

z

Check spark plugs, see IGNITION SYSTEM,

SERVICING

z

Check ignition coils with power output stage, see
IGNITION COILS WITH POWER OUTPUT

STAGE, CHECKING

z

Injector malfunctioning

z

Check injectors, see FUEL INJECTORS,

CHECKING
