Fig. 26: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Battery voltage must be at least 11.5 volts.

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

Parking brake must be engaged or else daylight driving lights will be switched on.

If vehicle is equipped with an A/C system, it must be switched off.

Ground (GND) connections between engine and chassis must be OK.

Ignition switched off.

Test sequence

Measure resistance between terminals of the respective valve for camshaft adjustment.

Specified value: 10...18 ohm

2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle

Fig. 27: Measuring Resistance Between Terminals Of Camshaft Adjustment Valve (Engine code
AWP, AWV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle

If specified value is not obtained:

Replace the valve for camshaft adjustment, see item 10 .

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .

generate readiness code, see READINESS CODE, GENERATING .

If specified value is obtained:

Connect test box to control module wiring harness, see CONNECT TEST BOX FOR WIRING TEST .

Check wire between test box socket 115 + 2 -pin connector terminal 2 for open circuit according to
wiring diagram.

Wire resistance: max. 1.5 ohm

Fig. 28: Identifying Harness Connector Terminals Of Camshaft Adjustment Valve (Engine code
AWP, AWV)

2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Also check wires for short circuit to B+ and Ground (GND).

Specified value: INFINITY ohm
