Volkswagen New Beetle. Manual - part 1485

1. Cover

2. Seal

z

Replace if damaged

3. 1 N.m

4. Tank flap unit

z

With rubber cup

5. 10 N.m

6. Breather pipe

7. Change-over valve

z

To remove valve unclip sideways out of socket

z

Remove cap item -1- before installing

z

Check. See Checking Change-Over Valve

8. O-ring

z

Replace if damaged

9. To EVAP canister

z

See EVAP SYSTEM COMPONENTS, SERVICING

10. Cable guide

z

In longitudinal member

11. Breather pipe

z

Check if seated securely

z

Secure with spring-type clips

12. Fuel tank

z

When removing, support with engine/transmission jack V.A.G 1383 A

z

Removing and installing. See FUEL TANK, REMOVING AND INSTALLING

13. Heat shield

z

For fuel tank

14. Clamping washer

15. Fuel tank cover

16. 20 N.m + 1/4 turn (90°) further

z

Replace

17. Securing strap

z

Note differing lengths

z

Installed position: Fixing point (holes) point in direction of travel (forward)

18. Fuel filter

z

Installed position: Arrow points in direction of flow

Engine codes BEV, BGD:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Removing and installing fuel pressure regulator. See Removing And Installing Fuel Pressure
Regulator

z

If fuel filter has been replaced, fuel system must be bled. See FUEL SYSTEM, BLEEDING .

19. Screw-type clip

z

Observe installed position. See Installed Position Of Screw-Type Clamp For Fuel Filter

20. Supply line

z

Black

z

Check if seated securely

z

To pull off of fuel filter press locking ring inward on connecting piece

21. Breather pipe

z

White

z

Clipped onto top of fuel tank

z

Check if seated securely

z

To EVAP canister purge regulator valve -N80-.

22. Seal

z

Replace if damaged

z

When installing, insert seal dry into fuel tank opening

z

Moisten with fuel only when installing fuel delivery unit flange.

23. Fuel delivery unit

z

Observe installed position of flange on fuel tank. See Installed Position Of Flange Of Fuel
Delivery Unit .

z

Removing and installing. See FUEL DELIVERY UNIT, REMOVING AND INSTALLING .

z

Removing and installing fuel gauge sender. See FUEL GAUGE SENDER, REMOVING AND
INSTALLING .

z

Checking fuel pump. See FUEL PUMP, CHECKING .

z

Clean strainer if soiled

24. Union nut, 75 N.m

z

Remove and install with key 3217

25. Supply line

z

Black

z

Check if seated securely

z

Clipped onto side of fuel tank

z

When pulling off flange and fuel filter press locking ring on connecting piece

26. Return line

z

Blue or with blue marking

z

Clipped onto side of fuel tank

z

Check if seated securely

z

To remove from flange press release button on connecting piece



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Engine codes BEV, BGD:

z

From fuel filter

All other engines:

z

From fuel return line on fuel rail

27. Gravity valve

z

To remove valve unclip upward out of support

z

Check valve for through flow, Valve vertical: Open; Valve tilted 45° : Closed

28. Pressure retention valve

z

For fuel tank breather

z

Checking. See Checking Pressure Retention Valve

29. Ground connection

z

Check if seated securely

Fig. 3: Exploded View Of Fuel Tank/Fuel Filter Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installed Position Of Flange Of Fuel Delivery Unit

Marking on sender must align with the marking on fuel tank (arrows).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 4: Aligning Fuel Delivery Unit Flange With The Marking On Fuel Tank
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Blue or blue marked return line -1- to connection with identification -R-.

Black supply line -2- to connection with identification -V-.

Checking Change-Over Valve

Lever in rest position: Closed

Lever pushed in direction of arrow: Open

Fig. 5: Checking Change-Over Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

After installing fuel delivery unit flange, check that the supply, return and
breather pipes are still clipped onto the fuel tank.
