Work sequence Observe safety precautions, See SAFETY PRECAUTIONS WHEN WORKING ON THE FUEL SUPPLY Observe rules for cleanliness. See RULES FOR CLEANLINESS . Connect remote control z Remove cover from fuel gauge sensor. z Disconnect 4-pin connector on fuel gauge sensor. z Connect remote control V.A.G 1348/3 A with adapter cables from V.A.G 1594 A to fuel pump contact - z Bridge contact -4- of connector and fuel pump using adapter cables from V.A.G 1594 A. Fig. 28: Connecting Remote Control With Adapter Cables To Fuel Pump Connector Checking delivery pressure and delivery rate z Pull fuel supply hose -1 - off fuel line at suspension strut and connect pressure gauge V.A.G 1318 with
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW
|
