22. Distance piece

23. Gravity/overflow valve

z

Check valve for through flow:

Valve vertical: Open,

Valve tilted 45°: Closed

24. 10 N.m

Fig. 1: Exploded View Of Fuel Tank Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Fuel gauge sensor, installed position

Mark on flange must align with mark on fuel tank (arrows).

Fig. 2: Mark On Fuel Gauge Sensor Flange Must Align With Mark On Fuel Tank
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



Vent valve, checking

Lever in rest position: Closed

Fig. 3: Checking Vent Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Lever pushed in direction of arrow: Open

FUEL FILTER, SERVICING

The flow direction is marked by an arrow on the fuel hose, the preheat valve and the fuel filter.

1. Return hose

z

To fuel cooler, See FUEL COOLER, REMOVING AND INSTALLING

z

Open lower spring-type clamp

z

Blue or with blue marking

z

Check for secure seating

2. Supply line

z

From fuel tank

z

White or with white marking

z

Check for secure seating

NOTE:

After installing fuel gauge sensor, check that the supply -2- and return lines -1-
are still clipped onto fuel tank.

NOTE:

Before installing breather valve, unscrew filler cap from fuel tank.

NOTE:

The following list refers to items in Fig. 4 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



3. O-ring

z

Always replace

4. Securing clip

z

Replace if damaged

5. Protective plate

z

Note installation position

6. Control valve

z

Installed position: Arrow points toward fuel tank

z

When changing filter, remove retaining clip and protective plate and take off preheat valve with
hoses remaining connected. Replace O ring and coat with fuel before installing.

z

Below + 15°C:

Passageway to filter open

z

Over + 31°C:

Passageway to filter closed

7. Return line

z

From tandem pump

z

Open lower spring-type clamp

z

Check for secure seating

8. Supply line

z

To tandem pump

z

Check for secure seating

9. Fuel filter

z

Fill with diesel before installing

z

Flow direction is marked by arrows

z

Do not interchange connections

z

Replace if damaged

10. Tensioning bolt, 2 N.m

11. Bracket

z

Slide onto upper stop of fuel filter

12. Water drain plug

z

To bleed: remove retaining clip and protective plate and remove preheat valve with hoses
remaining connected

z

Loosen and allow approx. 100 cc of fluid to drain

13. Seal

z

Replace if damaged.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



14. 10 N.m

Fig. 4: Identifying Fuel Filter Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

SAFETY PRECAUTIONS WHEN WORKING ON THE FUEL SUPPLY SYSTEM

When removing and installing the fuel gauge sensor from a full or partly full fuel tank, observe the following:

z

Before starting repairs, switch on exhaust extraction system and place an extraction hose close to the
sensor opening in the fuel tank to extract escaping diesel fuel fumes. If no exhaust extraction system is
available, a radial fan (as long as motor is not in air flow) with a displacement greater than 15 m

3

 /h can

be used.

z

Avoid fuel contact with skin! Wear fuel-resistant gloves!

CAUTION: When performing repair work, especially due to the confined conditions in

the engine compartment, pay attention to the following:

z

Route all types of hoses/lines (e.g. for fuel, hydraulics, EVAP system,
coolant, refrigerant, brake fluid and vacuum) as well as electrical
wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving or hot components.

WARNING:

z

The fuel and the fuel lines in the fuel system can become very hot
(danger of scalding)!

z

The fuel system is under pressure! Before opening the system,
place cloths around the connections. Then carefully loosen the
connection to release pressure

z

Wear eye and hand protection when performing any type of repair
work on the fuel system!
