Volkswagen New Beetle. Manual - part 1443

z

V.A.G 1348/3 A Remote control

Fig. 26: Identifying Special Tools And Equipment (V.A.G 1348/3 Remote Control)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1594 A Adapter set

Fig. 27: Identifying Special Tools And Equipment (V.A.G 1594 Adapter Set)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Voltage supply OK.

z

Battery charge at least 12.5 V

z

Fuel temperature 15°C to 30°C

z

Fuel according to DIN EN 590 - no biodiesel

z

Fuel tank filled at least 1/4



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



Work sequence

Observe safety precautions, See SAFETY PRECAUTIONS WHEN WORKING ON THE FUEL SUPPLY
SYSTEM .

Observe rules for cleanliness. See RULES FOR CLEANLINESS .

Connect remote control

z

Remove cover from fuel gauge sensor.

z

Disconnect 4-pin connector on fuel gauge sensor.

z

Connect remote control V.A.G 1348/3 A with adapter cables from V.A.G 1594 A to fuel pump contact -
1- and battery positive (+).

z

Bridge contact -4- of connector and fuel pump using adapter cables from V.A.G 1594 A.

Fig. 28: Connecting Remote Control With Adapter Cables To Fuel Pump Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking delivery pressure and delivery rate

z

Pull fuel supply hose -1 - off fuel line at suspension strut and connect pressure gauge V.A.G 1318 with
adapter V.A.G 1318/23 and V.A.G 1318/17-8 to fuel line.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 29: Checking Fuel Delivery Pressure
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Push hose V.A.G 1318/1 onto adapter V.A.G 1318/11 on pressure gauge and hold hose in a measuring
container.

z

Close shut-off tap of pressure gauge (item -A-).

z

Operate remote control again for approx. 5 seconds.

There must be measured a pressure of 0.5 +/- 0.1 bar in pressure gauge.

If delivery pressure is not achieved:

z

Check fuel line to fuel gauge sensor.

If delivery pressure OK:

z

Replace fuel gauge sensor, See FUEL DELIVERY UNIT, REMOVING AND INSTALLING .

When delivery pressure is achieved, check delivery rate as follows:

z

Open shut-off tap on pressure tester. Lever then points in through flow direction -B-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 30: Checking Fuel Delivery Rate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Operate remote control V.A.G 1348/3A. Close shut-off tap slowly, until pressure gauge shows 0.2 bar
pressure.

z

Do not continue to operate remote control. From this point on do not move position of shut-off tap.

z

Empty measuring container and position under drain hose again.

z

Operate remote control for 30 seconds and measure fuel quantity.

Specification: at least 660 ml/30 s.

If the minimum delivery rate is not attained:

z

Check fuel line to fuel gauge sensor.

If delivery rate is OK:

z

Replace fuel gauge sensor. See FUEL DELIVERY UNIT, REMOVING AND INSTALLING .

TANDEM PUMP, CHECKING

Special tools and equipment

z

VAS 5187 Pressure gauge
