Fig. 6: Identifying VAG 1331 Torque Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Note safety precautions before starting work. See SAFETY PRECAUTIONS WHEN WORKING ON
THE FUEL SUPPLY SYSTEM .

z

Open fuel filler.

z

With ignition switched off disconnect battery Ground strap.

z

Remove rear axle:

See FRONT AXLE SHAFT .

z

Remove right rear wheel housing liner:

See REAR WHEEL HOUSINGS LINER, ASSEMBLY OVERVIEW .

z

Remove cover from fuel reservoir (arrows).

CAUTION: Obtain radio anti-theft code before disconnecting battery Ground

strap.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 7: Removing Cover From Fuel Reservoir
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Drain fuel tank, clean fuel filler neck and surrounding area.

z

Disconnect vent lines at filler neck

z

Press separated vent hose through opening in long member in fuel tank direction.

z

Remove mounting bolts on filler neck.

z

Fold rear bench seat forward.

z

Remove fuel gauge sensor cover plate.

z

Disconnect fuel supply and return lines front, right at fuel reservoir

Fig. 8: Disconnecting Fuel Supply And Return Lines Front
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove tensioning strap. While removing strap, support fuel tank with VAG 1383 A engine/transmission
jack.

NOTE:

Press buttons on hose couplings (arrows) to do this.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - 1.9L 4-Cyl. - ALH, New Beetle



z

Lower fuel tank.

Installing

Installation is carried out in the reverse order of the removal procedure. Note the following during installation:

z

Guide vent lines through opening in long member (install wiring guide)

z

Secure vent lines at filler neck with clamps

z

Route breather hoses kink free.

z

Do not interchange supply and return hoses (return: blue or blue markings, supply: black).

z

Clip supply and return lines onto fuel tank.

ACCELERATOR MECHANISM, SERVICING

1. 10 N.m (7 ft lb)

2. Throttle Position (TP) sensor -G79-

z

Checking. See THROTTLE POSITION SENSOR, CHECKING .

z

Adjusting: See THROTTLE POSITION SENSOR, ADJUSTING .

z

Remove if instrument panel and/or pedal cluster cover require removal

3. Cable cam

4. Spring washer 5-10 N.m (7 ft lb)

5. Threaded piece

6. Mounting bracket

z

Self-locking hex nut, 20 Nm (15 ft. lb)

Fig. 9: Disassembled View Of Accelerator Mechanism
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The following list refers to items in Fig. 9 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - 1.9L 4-Cyl. - ALH, New Beetle



THROTTLE POSITION SENSOR, CHECKING

Special tools and equipment

z

Fluke 83 multimeter

z

VW 1594 Adaptor kit

z

VAG 1598/22 Test Box

z

VAG 1551/1552 Scan Tool with VAG 1551/3 adaptor cable

z

Wiring diagram

Fig. 10: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test sequence

z

Connect VAG 1551/1552 Scan Tool:

See VAG1551/1552 Scan Tool, Connecting .

z

Make sure that ignition is switched ON.

z

Press 0 and 1 buttons to select Address word 01: "Engine electronics".

Display will appear as shown in Fig. 11
