Volkswagen New Beetle. Manual - part 1430

Fig. 54: V.A.G 1551 Scan Tool Display - Checking EVAP System For Leak (7 Of 11)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The Leak detection pump V144- switches off and the control module measures the time until the reed contact
closes.

Indicated on display

Fig. 55: V.A.G 1551 Scan Tool Display - Checking EVAP System For Leak (8 Of 11)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check display in display zones 3 and 4: specified value display field 3: Check. END Specified value
display field 4: Syst. OK

DISPLAY IN DISPLAY ZONE CHECK

-

Display zones

1

2

3

4

Display group 71: Diagnosis of Evaporative Emission (EVAP) system (leak detection)

Display

Reed closed

Reed open

Small leak/large leak

Abort

Syst. Test

Check

Check end

Test OFF/Test ON

Syst. OK

Syst. not OK

Indicated

Condition Reed contact

Malfunction message

System condition

Result

Working
range

-

-

-

-

Specified

Reed open

-

Messg. END

Syst. OK



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



If the specifications are obtained:

z

Press --> button.

z

Press buttons -0- and -6- for function "End output" and confirm entry with -Q- button.

z

Switch ignition off.

If the specifications are not attained:

z

Press buttons -0- and -8- for "Read Measuring Value Block" function and confirm entry with Q button.

Indicated on display

Fig. 56: V.A.G 1551 Scan Tool Display - Checking EVAP System For Leak (9 Of 11)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press buttons -0-, -7- and -0- for "Display group number 70" and confirm entry with -Q- button.

Indicated on display: (1-4 = Display zones)

value

If a malfunction message

is indicated:

See CHECKING FOR

LEAKS checking for

leaks

If the specifications are not obtained: Check DTC memory,
See Diagnostic Trouble Code (DTC) Memory, Checking
And Erasing



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 57: V.A.G 1551 Scan Tool Display - Checking EVAP System For Leak (10 Of 11)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press button -4- for "Basic setting" function ("Tank venting valve diagnosis" will be initiated).

Indicated on display: (1-4 = Display zones)

NOTE:

The engine must not be loaded during this diagnosis because the diagnosis will
be interrupted and will not be started again until the engine is revved-up.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 58: V.A.G 1551 Scan Tool Display - Checking EVAP System For Leak (11 Of 11)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

When the diagnosis is initiated by the Engine Control Module, the display in display zone 4 jumps from "Test
OFF" to "Test ON."

z

Run engine at idling speed until specification "EVAP OK" is displayed in display zone 4.

DISPLAY IN DISPLAY ZONE CHECK

NOTE:

If the display jumps from "Test ON" to "Test OFF" during the test, rev up briefly
and the test will be repeated.

-

Display zones

1

2

3

4

Display group 70: Evaporative Emission (EVAP) system diagnosis (tank venting system)

Display

xxx.x %

xxx.x %

xxx %

Test OFF/Test ON

EVAP

(1)

 OK

EVAP not OK

Indicated

Opening of EVAP canister

purge regulator valve

during diagnostic

oxygen sensor

control value

Bank 1

Condition of EVAP

canister purge regulator

valve

(relative EVAP -

specification)

Diagnostic

condition and

Diagnostic result

Working

0.0-100.0%

-100.0-100.0%

0-199%

-
