Fig. 157: Scan Tool Display - Vehicle Speed Signal (2 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Press -0- and -8- buttons to select Function 08: "Read measuring value block".

z

Press -Q- button to enter input.

Display will appear as shown:

Fig. 158: Scan Tool Display - Vehicle Speed Signal (3 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0-, -0- and -6- buttons to select "Display group 6".

z

Press -Q- button to enter input.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Display will appear as shown (1 to 4 = Display zones):

Fig. 159: Scan Tool Display - Vehicle Speed Signal (4 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Take a test drive using a 2nd technician to observe display.

z

Observe value in Display zone 1

z

Specification: approx. speedometer display

If no speed indicated:

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 160: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect LED test light between sockets:

Up to MY 1999

z

1 (Ground) and 51 (road speed signal).

From MY 2000
