Fig. 4: Identifying Special Tools For Removing & Installing Diesel Injection Pump (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools, continued

z

2068A Adj. gauge TDC

z

3035 Injector line wrench

z

VAG1331 Torque wrench 5 to 50 Nm (3.7 to 37 ft lb) or equivalent

Fig. 5: Identifying Special Tools For Removing & Installing Diesel Injection Pump (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Diesel injection pump, removing

WARNING:

Fire hazard! Do NOT have anything in the area that can ignite Diesel fuel.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Unbolt all fuel lines at fuel pump.

z

Cover openings with a clean cloth.

z

Remove connecting line between charge air cooler and intake manifold.

z

Remove upper toothed belt guard and valve cover.

z

Remove vacuum pump for brake servo.

z

Turn crankshaft to cyl. 1 TDC (arrow).

Fig. 6: Turning Crankshaft To Cyl. 1 TDC (Manual Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft to cyl. 1 TDC (arrow)

Fig. 7: Turning Crankshaft To Cyl. 1 TDC (Automatic Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Use 3035 tubing wrench to loosen the high pressure fuel lines.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

for Automatic transmission

With engine removed

Vehicles with manual transmission

z

Install 2068 A TDC gauge as shown.

z

Set adjustment device to 96 mm (arrow -A-).

z

Left-hand notch of the vernier scale is the reference point.

z

Turn crankshaft until flywheel TDC marking aligns with point of setting device (arrow -B-).

Fig. 8: Setting Adjustment Device & Turning Crankshaft Until Flywheel TDC Marking Aligns
With Setting Device (Manual Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with automatic transmission

z

Install 2068 A TDC gauge as shown.

z

Set adjustment device to 30 mm (arrow -A-).

z

Left-hand notch of the vernier scale is the reference point.

z

Turn crankshaft until TDC marking on drive plate aligns with point of setting device (arrow -B-).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 9: Setting Adjustment Device & Turning Crankshaft Until Flywheel TDC Marking Aligns With
Setting Device (Automatic Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

All vehicles

z

Lock camshaft with setting bar.

Fig. 10: Locking Camshaft With Setting Bar 3418
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Centralize setting bar as follows:

Turn camshaft so that one end of setting bar contacts the cylinder head. Using feeler gauge, establish the gap at
the other end of the setting bar. Place a feeler gauge corresponding to half the gap between setting bar and
cylinder head. Turn camshaft until the setting bar contacts the feeler gauge. Place a 2nd feeler gauge, of same
thickness, at the other end between the setting bar and cylinder head.

z

Remove injection pump sprocket mounting bolts -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
