Fig. 178: Scan Tool Display - Transmission Range Selector Signal (1 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 179: Scan Tool Display - Transmission Range Selector Signal (2 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -8- buttons to select Function 08: "Read measuring value block".

z

Press -Q- button to enter input.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 180: Scan Tool Display - Transmission Range Selector Signal (3 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0-, -0- and -9- buttons to select "Display group 9".

z

Press -Q- button to enter input.

z

Take a test drive and observe display using 2nd technician.

z

Observe value in Display zone 3 when changing 2nd gear

z

Specification: momentarily less than 51 mg/h

WARNING:

Secure Scan Tool to rear seat and operate from this position using a
second technician.

NOTE:

Data transfer is slow, making it possible for delayed displays.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



If specification not obtained:

z

Press -> button.

Display will appear as shown:

Fig. 181: Scan Tool Display - Transmission Range Selector Signal (4 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -6- buttons to select Function 06: "End output".

z

Press -Q- button to enter input.

z

Switch OFF ignition.

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.
