Fig. 162: Scan Tool Display - Throttle Position Sensor, Up To MY 99 (2 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -8- buttons to select Function 08: "Read measuring value block".

z

Press -Q- button to enter input.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 163: Scan Tool Display - Throttle Position Sensor, Up To MY 99 (3 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press 0, 0 and 2 buttons to select "Display group 2".

z

Press -Q- button to enter input.

z

Observe value in Display zone 2 (Throttle Position).

z

Specification: 0.0% (pedal not operated)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 164: Scan Tool Display - Throttle Position Sensor, Up To MY 99 (4 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Observe value in Display zone 3.

z

Specification:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 165: Scan Tool Display - Throttle Position Sensor, Up To MY 99 (5 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

0 1 0 (pedal not operated)

0 0 0 (pedal operated)

z

Press accelerator pedal down slowly.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
