Fig. 46: Scan Tool Display - Engine Coolant Temperature Sensor (5 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

{

Press -0- and -6- buttons to select Function 06: "End output".



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



{

Press -Q- button to enter input.

{

Switch OFF ignition.

{

Disconnect -G62- harness connector (arrow).

Fig. 47: Disconnecting ECT Sensor -G62- Harness Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Measure resistance between sensor terminals 1 + 3.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 48: Identifying Resistance Between ECT Sensor Terminals 1 And 3
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Specification (see diagram):

Scale A shows resistance values for temperature range 0 to 50 °C and scale B the values for temperature range
50 to 100 °C.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 49: ECT Sensor Resistance Versus Temperature Range Graph
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Examples:

z

30 °C corresponds to a resistance from 1500 to 2000 ohm

z

80 °C corresponds to a resistance from 275 to 375 ohm

If specification not obtained:

z

Replace Engine Coolant Temperature (ECT) Sensor -G62-.

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

If specification obtained:

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
