Fig. 27: Identifying VAG 1331 Torque Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

3035 Injector line wrench

Fig. 28: Identifying 3035 Injector Line Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Faulty injectors can cause the following malfunctions:

z

Misfiring

z

Knocking in one or more cylinders

z

Engine over-heating

z

Loss of power

z

Excessive black exhaust smoke

z

Higher fuel consumption

z

Excessive blue smoke when starting with cold engine



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fuel Injectors, removing

z

Remove injection lines using 3035 tubing wrench.

z

Remove mounting nut, retainer and pull out fuel injector.

Fuel injectors, installing

z

Insert fuel injector.

z

Make sure mount is seated correctly in cylinder head and install retainer.

Tightening torques:

z

Injection lines = 25 Nm (18 ft lb)

z

Retainer screw = 20 Nm (15 ft lb)

z

Erase DTC memory. See DTC MEMORY, ERASING . Set the readiness code. See READINESS
CODE, SETTING .

Fuel injectors, servicing

The AHL engine is equipped with dual spring design injectors. Fuel is injected in 2 stages. These fuel injectors
must be replaced if malfunctions occur because neither servicing nor pressure adjustment is possible.

Special tools

z

VAG1322 Injector test stand with VAG1322/2 pressure line

Checking requirements

z

Pressure gauge on

Fuel injection pressure, checking

NOTE:

Faulty injectors can be located by loosening the high pressure line connection
on each injector in turn with the engine running at a fast idle. If engine speed
remains constant after loosening a line connection, this would indicate a faulty
injector.

NOTE:

Always remove fuel lines in a complete set. Do not alter line shape.

NOTE:

Always replace heat shield between cylinder head and fuel injectors.

WARNING:

When testing fuel injectors, make sure that the stream of fuel does not
contact your hands. The high pressure fuel delivery can penetrate skin



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Connect fuel injector to fuel injector test stand.

Fig. 29: Connecting Fuel Injector To Fuel Injector Test Stand
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Move pump lever down slowly. When spray begins, record opening pressure for deviations from
specification replace injector.

z

Specification (new injectors): 220 - 230 bar

z

Wear limit: 200 bar

Fuel injectors, leak-checking

z

Pressure gauge on

z

Move pump lever down slowly and maintain a pressure of approx. 150 bar for 10 seconds.

z

No fuel should leak from the nozzle tip.

z

If any injector(s) leak, replace.

Diesel injection pump timing cover O-ring, replacing

z

Place a clean cloth under the Diesel injection pump.

z

Remove cover screws -1- with commercially available tool for Torx socket head screws, e.g. Hazet 2115
-T30.

z

Remove cover -2- and clean thoroughly.

z

Replace O-ring -3- and install cover using existing shims -4-.

which could result in severe injuries.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 30: Removing Injection Pump Timing Cover Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

DIESEL FUEL INJECTION COMPONENTS AND FUNCTIONS, CHECKING

Diesel injection system Voltage supply, checking

Special tools

z

VAG1598/22 Test Box (MY 1999)

WARNING:

Make sure that no electronic components are destroyed during testing by
observing the following:

z

Switch the Fluke 83 multimeter to the appropriate units range before
connecting measuring cables!

z

Always observe checking requirements!

NOTE:

z

Use the Fluke 83 multimeter and VAG1527B Voltage tester for electrical
checking.

z

Specifications are valid for an ambient temperature range from: 0 to + 40 °
C (+32 to 104 °F).

z

If measured values deviate only slightly from the specifications, clean the
sockets and plugs on the tester and measuring cables, then repeat check.
Before replacing a component, check wiring and connections. In cases of
specifications less than 10 ohm repeat the resistance measurement on the
component.

z

To connect a tester to the Test Box, use jumper wires from the VW 1594
adapter kit.

z

The terminal numbers of the plugs and the socket numbers on the Test
Box are identical.
