Vehicles with engine code AEG as of 06.99, AVH, AZG, BDC

Test requirements

z

Pressure hose for Secondary Air Injection (AIR) Pump Motor not clogged or kinked

z

Hose connections must be properly sealed.

Test sequence

z

Remove front noise insulation.

z

Disconnect pressure hose (arrow) from Secondary Air Injection (AIR) pump motor.

Fig. 21: Disconnecting Pressure Hose From Secondary Air Injection Pump Motor (Engine Code
AEG From 06.99, And Engine Codes AVH, AZG, BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Blow with light pressure into pressure hose to combination valve. Combination valve must close.

z

Blow with high pressure into pressure hose to combination valve. Combination valve must open.

If the combination valve does not open or it is constantly open:

z

Replace the combination valve:

z

Vehicles with engine code AEG, AVH, AZG. See item 20 .

z

Vehicles with engine code BDC. See item 1 .

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .

NOTE:

Do not use pressurized air for the following test!

NOTE:

To disengage, compress the buttons at the hose coupling.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



z

Generate readiness code. See READINESS CODE, GENERATING .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



1998-2004 ENGINE

Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle

TURBOCHARGER, G-CHARGER

CHARGE AIR PRESSURE WITH TURBOCHARGER

Turbocharger system components, removing and installing

Observe rules for cleanliness. See RULES FOR CLEANLINESS .

1. Exhaust manifold

z

With turbocharger

z

Only replace as assembly

2. Intake manifold

3. from charge air cooler

4. Gasket

z

Replace

z

Coating (beading) toward intake manifold

5. 25 N.m (18 ft lb)

6. Gasket

z

Note installation position

7. Bracket

z

For heat shield (item -9-)

8. Washer

9. Heat shield

z

Engage in bracket (item -7-)

10. Turbocharger

z

Only replace as assembly

z

Removing: remove right drive shaft at transmission:

See FRONT AXLE SHAFT .

NOTE:

z

All hose connections are secured with clips.

z

Charge air pressure must be leak free.

z

Replace self-locking nuts.

NOTE:

The following list refers to items in Fig. 1 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle



z

Charge air pressure control, checking. See CHARGE AIR PRESSURE SYSTEM,
CHECKING .

11. Pressure unit

z

For charge air pressure control valve

z

Integral part of turbocharger; cannot be replaced

12. From Air Cleaner

13. Gasket

z

Replace

14. Sealing ring

z

Replace

15. Oil return pipe

z

To cylinder block

16. Banjo bolt

z

25 N.m (18 ft lb)

17. 15 N.m (11 ft lb)

18. 40 N.m (30 ft lb)

19. Bracket

20. 25 N.m (18 ft lb)

21. Gasket

z

Replace

22. Front exhaust pipe

23. Connection

24. 10 N.m (7 ft lb)

25. Oil supply pipe
