Fig. 78: Exploded View Of Cylinder Head Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking Cylinder Head For Distortion

Special tools, workshop equipment, testers, measuring instruments and auxiliary items required

z

Straight edge

z

Feeler gauges

Max. permissible distortion: 0.1 mm

Fig. 79: Checking Cylinder Head For Distortion
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Cylinder head, removing and installing

Special tools and equipment

z

VAG 1306 Drip tray



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

VAG 1332 Torque wrench (40-200 N.m)

z

VAG 1921 Hose clip pliers

z

3070 Installation tool with guide pins

z

VAS 5024 Assembly tool for spring-type clamps

Fig. 80: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engines with Polydrive cylinder head bolts:

z

3452 Tool

Requirements

z

The engine must be no more than warm to touch

Work sequence

z

Note safety precautions before starting work. See SAFETY PRECAUTIONS WHEN WORKING ON
FUEL SUPPLY .

z

Observe rules for cleanliness. See RULES OF CLEANLINESS .

z

Check whether a coded radio is installed. If so, obtain anti-theft coding.

z

With ignition switched off, disconnect battery Ground strap.

z

Remove engine cover.

z

Drain coolant. See COOLING SYSTEM, DRAINING AND FILLING .

z

Remove secondary air pump motor and bracket.

WARNING:

Fuel supply lines are under pressure! Before removing from hose
connection wrap a cloth around the connection. Then release
pressure by carefully pulling hose off connection.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Separate fuel supply as well as fuel return pipes at connection on fuel rail. Fuel system is under pressure,
therefore place a cloth over connection before hoses are pulled off.

z

Seal lines so that fuel system is not contaminated by dirt etc.

z

Remove coolant hose connections on cylinder head.

z

Remove inter-connecting, coolant, vacuum and intake hoses on engine.

z

Pull connector(s) off ignition coils.

z

Pull off/disconnect all other electrical connections as necessary from engine and lay to one side.

z

Remove intake air hose from connection of exhaust turbocharger as follows:

z

Pull off hose at pressure regulator valve of crankshaft ventilation.

z

Disconnect harness connector at Wastegate Bypass Regulator Valve -N75-.

z

Pull off hose at Wastegate Bypass Regulator Valve -N75-.

z

Disconnect hose from solenoid valve to turbocharger at bulkhead.

z

Disconnect hose between EVAP canister and exhaust turbocharger at bulkhead.

z

Pull out securing buckle at connector of exhaust turbocharger and remove air intake hose.

z

Remove heat protection pad 1 from air guiding hose 2 (observe installation position).

Fig. 81: Removing Heat Protection Pad 1 From Air Guiding Hose 2
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove air guiding hose 2.

z

Loosen 2 bolts from bracket of upper air guiding hose. See ONLY FOR ENGINE CODE APH , Item 8

z

Remove heat protection pad from air guiding hose (observe installation position) and loosen clamp 3.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 82: Removing Heat Protection Pad From Air Guiding Hose And Loosening Clamp 3
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove screws 1 and 4 for heat shield from behind cylinder head.

z

Loosen screws 2 and 5.

z

Remove air guiding hose, hose to turbocharger and heatshield.

z

Remove three exhaust gas turbocharger/exhaust manifold securing bolts -arrows-.

Fig. 83: Removing Three Exhaust Gas Turbocharger/Exhaust Manifold Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Remove tensioning element for ribbed belt.

z

Remove toothed belt guard (upper part).

z

Set camshaft sprocket to TDC No. 1 cylinder by turning crankshaft. Mark on camshaft sprocket must
align with arrow on toothed belt guard.
