z

Take off sealing flange, release using light blows with a rubber headed hammer if necessary.

z

Remove sealant residue on cylinder block with a flat scraper.

z

Remove sealant remains on sealing flange with a rotating plastic brush (wear protective goggles).

Fig. 56: Removing Sealant Remains On Sealing Flange With Rotating Plastic Brush
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Clean sealing surface, must be free of oil and grease.

Installing

z

Cut-off tube nozzle at forward marking (nozzle approx. 3 mm diameter).

z

Apply silicone sealing compound to clean oil pan sealing surface as shown.

NOTE:

z

Note the "use by" date of the sealant.

z

The sealing flange must be installed within 5 minutes o applying the
silicone sealant.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 57: Applying Silicone Sealing Compound To Clean Oil Pan Sealing Surface
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Thickness of sealant bead -arrows-: 2 - 3 mm

z

Apply silicone sealant bead as shown to clean sealing surface of sealing flange.

Fig. 58: Applying Silicone Sealant Bead To Clean Sealing Surface Of Sealing Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install sealing flange immediately and lightly tighten all bolts.

z

Tighten sealing flange securing bolts using alternate sequence.

Tightening torque: 15 N.m

z

Remove excess sealant.

z

Install oil pan. See OIL PAN, REMOVING AND INSTALLING .

z

Install crankshaft toothed belt sprocket and hold with counter-hold tool 3099.

NOTE:

The sealing compound bead must not be thicker, otherwise excessive
sealing compound will enter the oil pan and may block the oil suction pipe
strainer.

NOTE:

Use guide sleeve from 2080A to install sealing flange with the oil seal
already installed.

NOTE:

After installing, the sealant must be allowed to dry for approx. 30 minutes
before engine oil is filled.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 59: Installing Crankshaft Toothed Belt Sprocket And Holding With Counter-Hold Tool 3099
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten new central bolt to 90 N.m + 1/4 turn (90°) further.

z

Install compact bracket including tightening element for ribbed V-belt. See ) COMPACT BRACKET .

z

Install toothed belt and adjust valve timing. See INSTALLING .

z

Installing ribbed belt and tensioning element. See RIBBED BELT TENSIONER, REMOVING AND
INSTALLING .

Drive plate, removing and installing

Special tools and equipment

NOTE:

z

When bolting on, place two washers between toothed belt pulley and
counter-hold.

z

Thread and shoulder must be free of oil and grease.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 60: Identifying VW 558 Retainer
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VW 558 Retainer

z

Hex bolt M8x45 and two M10 hex nuts

z

Depth gauge

Loosening and tightening drive plate

z

Secure counter-hold tool VW 558 to the drive plate with a hex bolt M8x45. Place two M10 hex nuts -1-
between counter-hold tool and drive plate.

Fig. 61: Securing Counter-Hold Tool VW 558 To The Drive Plate With Hex Bolt M8x45
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosen drive plate bolts.

Installing drive plate

z

Locate drive plate and packing plate with recesses -1-.

z

Install new bolts -3- and tighten to 30 N.m.
